nginx配置https的双向认证方式_https

注意事项

配置双向认证，这里的common name需要都配置成不同

nginx 配置 https的双向认证

准备工作

linux环境安装openssl

生成证书步骤

1.新建一个文件夹

mkdir /root/keys

2.生成ca私钥 ca.key

openssl genrsa -out ca.key 4096

3.生成ca的数字证书 ca.crt

   openssl req -new -x509 -days 3650 -key ca.key -out ca.crt
   country name (2 letter code) [au]:
   state or province name (full name) [some-state]:
   locality name (eg, city) []:
   organization name (eg, company) [internet widgits pty ltd]:
   organizational unit name (eg, section) []:
   common name (e.g. server fqdn or your name) []:
   email address []:
   填入组织名称等信息

4.生成server端的私钥

openssl genrsa -out server.key 4096

5.生成 server 端数字证书请求

   openssl req -new -key server.key -out server.csr
   country name (2 letter code) [au]:cn
   state or province name (full name) [some-state]:shanghai
   locality name (eg, city) []:
   organization name (eg, company) [internet widgits pty ltd]:sidien test
   organizational unit name (eg, section) []:
   common name (e.g. server fqdn or your name) []:192.168.0.162
   email address []:

   please enter the following 'extra' attributes
   to be sent with your certificate request
   a challenge password []:
   an optional company name []:
  输入相关信息和密码

6.用 ca 私钥签发 server 的数字证书

openssl  x509 -req -in server.csr  -ca  ca.crt  -cakey  ca.key  -cacreateserial -out  server.crt  -days  3650

7. 生成客户端私钥

openssl  genrsa  -out  client.key  4096

8. 生成客户端数字请求证书

  openssl req -new -key client.key -out client.csr
   country name (2 letter code) [au]:
   state or province name (full name) [some-state]:
   locality name (eg, city) []:
   organization name (eg, company) [internet widgits pty ltd]:
   organizational unit name (eg, section) []:
   common name (e.g. server fqdn or your name) []:
   email address []:

   please enter the following 'extra' attributes
   to be sent with your certificate request
   a challenge password []:
   an optional company name []:
  输入相关信息和密码

9.用ca私钥签发数字证书:client.crt

openssl  x509 -req -in server.csr  -ca  ca.crt  -cakey  ca.key  -cacreateserial -out  client.crt  -days  3650

10.生成windows安装证书程序

openssl pkcs12 -export -inkey client.key -in client.crt -out client.pfx

将client.pfx拷贝到作为客户端的机器上，安装证书，输入生成时的密码

11.配置nginx

 ssl_certificate  /etc/pki/ca_linvo/server/server.crt;     #server公钥路径
 ssl_certificate_key  /etc/pki/ca_linvo/server/server.key;   #server私钥路径
 ssl_client_certificate   /etc/pki/ca_linvo/root/ca.crt;   #根级证书公钥路径，用于验证各个二级client
 ssl_verify_client on;   开启双向认证

认证成功

curl --cert ./client.crt --key ./client.key https://url -k -v

开启gzip跟缓存

gzip  on;

    gzip_min_length     256;
    gzip_buffers        4 16k;
    gzip_http_version   1.1;
    gzip_vary on;
    gzip_comp_level 3;
    gzip_disable "msie [1-6]\.";
    gzip_proxied any;
#这里设置需要压缩的格式
    gzip_types
	application/atom+xml
	application/javascript
	application/json
	application/ld+json
	application/manifest+json
	application/rss+xml
	application/vnd.geo+json
	application/vnd.ms-fontobject
	application/x-font-ttf
	application/x-web-app-manifest+json
	application/xhtml+xml
	application/xml
	font/opentype
	image/bmp
	image/svg+xml
	image/x-icon
	text/cache-manifest
	text/css
	text/plain
	text/vcard
	text/vnd.rim.location.xloc
	text/vtt
	text/x-component
	text/x-cross-domain-policy;
		location / {
	   root   /root/www/web;
	   index  index.html;
	   autoindex on;
            if ($request_filename ~ .*.(js|css)$)
         {
         expires 7d;
         }
	}
