Spring Boot 3.x GraalVM原生镜像构建内存溢出问题解决方案

error: image build request failed with exit status 137
# 或
fatal error: java.lang.outofmemoryerror
# 或
[pool-1-thread-1] gc warning: repeated allocation of very large block

# 启用详细gc日志
mvn -pnative clean package \
  -dnative.buildargs="-h:+printgc -h:+printgctimestamps" \
  -dverbose=true
# 使用jmx监控（需要jdk工具）
export native_buildtools_monitor=true
./mvnw -pnative clean package

# 查看内存峰值
/usr/bin/time -v ./mvnw -pnative clean package 2>&1 | grep -i "maximum"
# 使用系统监控工具
top -pid $(pgrep -f "native-image")
# 或
htop -p $(pgrep -f "native-image")

<!-- pom.xml配置 -->
<plugin>
    <groupid>org.graalvm.buildtools</groupid>
    <artifactid>native-maven-plugin</artifactid>
    <configuration>
        <buildargs>
            <buildarg>-h:+dashboardall</buildarg>
            <buildarg>-h:dashboarddump=build/reports/native/dump</buildarg>
            <buildarg>-h:+dashboardheap</buildarg>
            <buildarg>-h:+dashboardcode</buildarg>
        </buildargs>
    </configuration>
</plugin>

<!-- 调整maven/构建工具jvm参数 -->
<plugin>
    <groupid>org.apache.maven.plugins</groupid>
    <artifactid>maven-surefire-plugin</artifactid>
    <configuration>
        <argline>-xmx8g -xms4g -xx:maxdirectmemorysize=2g</argline>
    </configuration>
</plugin>
<plugin>
    <groupid>org.graalvm.buildtools</groupid>
    <artifactid>native-maven-plugin</artifactid>
    <configuration>
        <jvmargs>
            <!-- 为native-image进程设置jvm参数 -->
            <jvmarg>-xmx12g</jvmarg>
            <jvmarg>-xms6g</jvmarg>
            <jvmarg>-xx:maxdirectmemorysize=4g</jvmarg>
            <jvmarg>-xx:+useg1gc</jvmarg>
            <jvmarg>-xx:+usestringdeduplication</jvmarg>
        </jvmargs>
    </configuration>
</plugin>

# linux/mac
export maven_opts="-xmx12g -xms4g -xx:maxmetaspacesize=2g -xx:+useg1gc"
export graalvm_home=/path/to/graalvm
# windows
set maven_opts=-xmx12g -xms4g -xx:maxmetaspacesize=2g -xx:+useg1gc
set graalvm_home=c:\path\to\graalvm

<plugin>
    <groupid>org.graalvm.buildtools</groupid>
    <artifactid>native-maven-plugin</artifactid>
    <configuration>
        <buildargs>
            <!-- 堆内存设置 -->
            <buildarg>-j-xmx16g</buildarg>  <!-- native-image进程最大堆 -->
            <buildarg>-j-xms8g</buildarg>   <!-- native-image进程初始堆 -->
            <!-- 并行处理优化 -->
            <buildarg>-h:numberofthreads=4</buildarg> <!-- 根据cpu核心调整 -->
            <buildarg>-h:parallelism=4</buildarg>
            <!-- 内存使用策略 -->
            <buildarg>-h:maximumheapsizepercent=80</buildarg>
            <buildarg>-h:maximumcompilationtime=90</buildarg>
            <!-- 大页面支持（linux） -->
            <buildarg>-h:+uselargepages</buildarg>
            <buildarg>-h:largepagesizeinbytes=2m</buildarg>
            <!-- 启用压缩指针 -->
            <buildarg>-h:+usecompressedoops</buildarg>
        </buildargs>
    </configuration>
</plugin>

<buildargs>
    <!-- 启用分层编译 -->
    <buildarg>-h:-multitieraot</buildarg>
    <!-- 增量构建支持 -->
    <buildarg>-h:±useexperimentalincrementalbuild</buildarg>
    <!-- 模块化构建 -->
    <buildarg>-h:±buildoutputsilent</buildarg>
    <buildarg>-h:tracebuilder=modules</buildarg>
</buildargs>

// 优化前：全量反射配置
@registerreflectionforbinding({
    class1.class, class2.class, class3.class,
    class4.class, class5.class, class6.class,
    // ... 数百个类
})
// 优化后：精确配置，仅包含必要字段/方法
@registerreflectionforbinding(
    value = {userdto.class, pageresult.class},
    mode = registerreflectionforbinding.mode.selective
)
public class optimizedreflectionconfig {
    @bean
    @registerreflectionforbinding(
        value = complexdto.class,
        fields = {"id", "name", "createdat"}, // 仅注册必要字段
        methods = {"getid", "getname"}        // 仅注册必要方法
    )
    public service service() {
        return new service();
    }
}

@configuration
@nativehint(
    options = {
        // 关键：将非必要的库延迟初始化
        "--initialize-at-run-time=" +
            "com.fasterxml.jackson.databind," +
            "org.hibernate.validator," +
            "ch.qos.logback," +
            "io.netty",
        // 构建时必须初始化的核心类
        "--initialize-at-build-time=" +
            "org.springframework," +
            "com.example.core"
    },
    trigger = nativehinttrigger.class
)
public class lazyinitializationconfig {
    // 动态配置初始化时间
    @bean
    @conditionalonnativeimage
    public runtimehintsregistrar runtimehintsregistrar() {
        return hints -> {
            // 运行时才需要反射的类
            hints.reflection().registertype(
                dynamicproxyclass.class,
                membercategory.public_classes
            );
            // 延迟加载的资源
            hints.resources().registerpattern("dynamic/*.json");
        };
    }
}

// 1. 创建核心模块（必须构建时初始化）
@nativehint(
    options = "--initialize-at-build-time=com.example.core"
)
@configuration
public class coremoduleconfig {
    // 核心业务逻辑，最小化依赖
}
// 2. 创建扩展模块（可以运行时加载）
@nativehint(
    options = "--initialize-at-run-time=com.example.plugin",
    mode = nativehintmode.reflection_and_resources
)
@configuration
@conditionalonproperty(name = "plugin.enabled")
public class pluginmoduleconfig {
    // 可选功能，按需加载
}
// 3. 主应用配置
@springbootapplication
@import({coremoduleconfig.class})
public class modularapplication {
    @bean
    @conditionalonnativeimage
    public static runtimehintsregistrar moduleregistrar() {
        return hints -> {
            // 动态注册模块
            if (ispluginenabled()) {
                hints.reflection().registertype(
                    pluginservice.class,
                    membercategory.invoke_public_methods
                );
            }
        };
    }
}

# 多阶段构建，优化内存使用
from ghcr.io/graalvm/native-image:22.3.1 as builder
# 设置构建参数
env maven_opts="-xmx8g -xms4g -xx:maxmetaspacesize=1g"
env native_image_opts="-j-xmx12g -j-xms6g -h:maximumheapsizepercent=80"
# 使用zgc（jdk17+）
env java_tool_options="-xx:+usezgc -xmx10g -xms5g"
# 构建缓存优化
volume /root/.m2
volume /root/.gradle
# 构建脚本
copy . /app
workdir /app
# 分步构建，减少单次内存压力
run ./mvnw clean compile -dskiptests
run ./mvnw package -pnative -dskiptests \
    -dspring.aot.enabled=true \
    -dnative.buildargs="$native_image_opts"
# 最终镜像
from alpine:latest
copy --from=builder /app/target/*-runner /application
entrypoint ["/application"]

# github actions配置
jobs:
  build-native:
    runs-on: ubuntu-22.04-large  # 使用大内存实例
    env:
      maven_opts: "-xmx12g -xms6g -xx:maxmetaspacesize=2g"
      graalvm_opts: "-j-xmx14g -j-xms8g"
    steps:
    - name: setup graalvm
      uses: graalvm/setup-graalvm@v1
      with:
        version: '22.3.1'
        java-version: '17'
        components: 'native-image'
        native-image-job-reports: 'true'
    - name: build with memory optimization
      run: |
        # 分段构建策略
        mvn clean compile -dskiptests -t 4
        mvn package -pnative -dskiptests \
          -dnative.buildargs="
            -j-xmx14g
            -j-xms8g
            -h:numberofthreads=4
            -h:parallelism=4
            -h:maximumheapsizepercent=75
            -h:+printgc
            -h:+printgctimestamps
            -h:+heapdumponoutofmemoryerror
            -h:heapdumppath=./heapdump.hprof
          "
    - name: upload memory report
      if: failure()
      uses: actions/upload-artifact@v3
      with:
        name: native-build-reports
        path: |
          heapdump.hprof
          target/*.json
          target/reports/

<buildargs>
    <!-- 控制分析范围 -->
    <buildarg>-h:analysismaxnodes=1000000</buildarg> <!-- 限制分析节点数 -->
    <buildarg>-h:analysisrootsscope=app</buildarg>   <!-- 限制分析根范围 -->
    <!-- 内存使用策略 -->
    <buildarg>-h:analysistimefile=analysis-time.json</buildarg>
    <buildarg>-h:+analysisresultasgraph</buildarg>
    <!-- 去除不需要的分析 -->
    <buildarg>-h:-analysistime</buildarg>
    <buildarg>-h:-printanalysiscalltree</buildarg>
</buildargs>

# 第一步：生成profiling信息
java -dspring.aot.enabled=true \
     -agentlib:native-image-agent=config-output-dir=./config,\
     caller-filter-file=./filter.json,\
     builtin-caller-filter=true \
     -jar target/application.jar
# 运行典型工作负载
# 第二步：使用pgo构建
mvn -pnative package \
  -dnative.buildargs="
    -j-xmx16g
    -h:profilefile=./config/profile.iprof
    -h:+profileguidedoptimization
    -h:pgoinstrtimefile=./config/pgo-time.txt
  "

// 使用@conditionalonclass避免不必要的类加载
@configuration(proxybeanmethods = false)
@conditionalonclass(name = {
    "com.fasterxml.jackson.databind.objectmapper",
    "org.springframework.http.converter.json.jackson2objectmapperbuilder"
})
@autoconfigurebefore(jacksonautoconfiguration.class)
public class optimizedjacksonconfig {
    // 仅当jackson存在时才配置
}
// 使用@importruntimehints进行提示注册
@importruntimehints(optimizedhintsregistrar.class)
@configuration
public class optimizedconfiguration {
    static class optimizedhintsregistrar implements runtimehintsregistrar {
        @override
        public void registerhints(runtimehints hints, classloader classloader) {
            // 动态计算需要注册的类
            if (isfeatureenabled("feature-x")) {
                hints.reflection().registertype(featurex.class);
            }
        }
    }
}

<configuration>
    <buildargs>
        <!-- 极端内存优化配置 -->
        <buildarg>-j-xmx4g</buildarg>
        <buildarg>-j-xms2g</buildarg>
        <buildarg>-j-xx:maxdirectmemorysize=512m</buildarg>
        <buildarg>-j-xx:+useserialgc</buildarg>  <!-- 串行gc，减少内存开销 -->
        <buildarg>-h:numberofthreads=2</buildarg> <!-- 减少线程数 -->
        <buildarg>-h:maximumheapsizepercent=60</buildarg>
        <buildarg>-h:maximumcompilationtime=95</buildarg>
        <!-- 禁用非必要特性 -->
        <buildarg>-h:-addallcharsets</buildarg>
        <buildarg>-h:-enableurlprotocols</buildarg>
        <buildarg>-h:-addallfilesystemproviders</arg>
        <!-- 简化分析 -->
        <buildarg>-h:analysismaxnodes=500000</buildarg>
        <buildarg>-h:-collectanalysisresults</buildarg>
    </buildargs>
</configuration>

# 使用google cloud build
gcloud builds submit --config=cloudbuild.yaml \
  --machine-type=e2-highcpu-32 \
  --disk-size=200
# cloudbuild.yaml
steps:
- name: 'gcr.io/cloud-builders/maven'
  args: ['package', '-pnative', '-dskiptests']
  env:
    - 'maven_opts=-xmx30g -xms16g'
    - 'native_image_opts=-j-xmx32g'

#!/bin/bash
# monitor-native-build.sh
set -e
start_time=$(date +%s)
memory_limit=16000  # 16gb in mb
echo "开始native image构建监控..."
echo "内存限制: ${memory_limit}mb"
echo "时间: $(date)"
# 监控内存使用
monitor_memory() {
    local pid=$1
    local max_mem=0
    while kill -0 $pid 2>/dev/null; do
        local mem=$(ps -o rss= -p $pid | awk '{print int($1/1024)}')
        if [ $mem -gt $max_mem ]; then
            max_mem=$mem
        fi
        if [ $mem -gt $memory_limit ]; then
            echo "错误: 内存使用超过限制 (${mem}mb > ${memory_limit}mb)"
            kill -9 $pid
            exit 1
        fi
        sleep 5
    done
    echo "最大内存使用: ${max_mem}mb"
}
# 执行构建
mvn -pnative clean package \
  -dnative.buildargs="-j-xmx${memory_limit}m -h:+printgc -h:+printgctimestamps" \
  -dskiptests &
build_pid=$!
# 启动监控
monitor_memory $build_pid
# 等待构建完成
wait $build_pid
build_status=$?
end_time=$(date +%s)
duration=$((end_time - start_time))
echo "构建时长: ${duration}秒"
echo "结束时间: $(date)"
exit $build_status

@springboottest
@disabledonnativeimage  // 不在native测试中运行
class nativeimagememorytest {
    @test
    void verifynativeimageconfiguration() {
        // 验证反射配置是否完整
        assertdoesnotthrow(() ->
            class.forname("com.example.dto.userdto")
                 .getdeclaredmethod("getid")
        );
        // 验证资源文件
        assertnotnull(getclass().getresource("/meta-inf/native-image/resource-config.json"));
        // 内存使用检查
        runtime runtime = runtime.getruntime();
        long usedmemory = runtime.totalmemory() - runtime.freememory();
        long maxmemory = runtime.maxmemory();
        asserttrue(usedmemory < maxmemory * 0.8,
            "内存使用应小于最大内存的80%");
    }
    @test
    @conditionalonnativeimage
    void nativeimagespecifictest() {
        // native镜像特有的测试
        asserttrue(imageinfo.inimagecode(), "应在native image中运行");
    }
}
