vue简单实现一个虚拟列表的示例代码_Javascript

一、前言

当今的时代是大数据时代，往往一个列表就有成千上万条数据，而我们一一渲染的话，则需要耗费大量时间，导致网页打开缓慢。懒加载虽然减少了第一次渲染时间，加快了网页打开速度，但随着后续数据的不断载入拼接，列表的渲染时间也会越来越长。虚拟列表则很好的解决了这一问题。

虚拟列表只渲染当前可视区域的列表，并不会将所有的数据渲染。下面用vue简单实现移动端虚拟列表（并且支持下拉触底加载效果）

二、代码实现

准备下拉数据：

export default {
  data() {
    return {
      listdata: [], // 总数据
      isloading: false, // 展示loading
    };
  },
  mounted() {
    this.getlistdata();
  },
  methods: {
    // 获取数据
    getlistdata() {
      const count = 20 + this.listdata.length;
      const start = this.listdata.length;
      this.isloading = true;
      settimeout(() => {
        for (let i = start; i < count; i++) {
          this.listdata.push(i);
        }
        this.isloading = false;
      }, 500);
    },
  },
};

需要准备内外两个列表容器，外部容器(viewport)固定高度用于生成滚动条，内部容器(scrollbar)用于撑开外部容器使得滚动条保持与未使用虚拟列表时一致。

<template>
  <div class="viewport" ref="viewport">
    <!-- 滚动条 -->
    <div class="scrollbar" :style="{ height: listheight + 'px' }"></div>
    <!-- 展示的列表 -->
    <div
      class="list"
      :style="{ transform: `translatey(${transformoffset}px)` }"
    >
      <div
        class="row"
        :style="{ height: rowheight + 'px' }"
        v-for="(item, index) in showlist"
        :key="index"
      >
        <slot :record="item"></slot>
      </div>
    </div>
    <!-- 加载 -->
    <div class="loading_wrap" v-show="loading">
      <div class="loading">
        <div class="container"></div>
      </div>
      <div>正在加载中</div>
    </div>
  </div>
</template>

<style lang="less" scoped>
/*
------最外层容器---------*/
.viewport {
  width: 100%;
  height: 100%; // 这个的高度让父组件去决定
  background-color: #fff;
  position: relative;
  overflow-y: auto;
}
/*
------列表展示层容器---------*/
.list {
  position: absolute;
  top: 0;
  left: 0;
  right: 0;
}
/*
------每行容器---------*/
.row {
  overflow: hidden;
}

</style>

计算列表的总高度listheight（列表的总条数乘以每一条的高度），可视区域的高度viewheight。

计算当前可见区域起始数据的startindex和结束数据的endindex，监听viewport列表滚动事件，计算currentindex以及列表的偏移量transformoffset。

监听滚动事件动态设置显示的列表（showlist）。

<script lang="ts" setup>
import {
  defineprops,
  withdefaults,
  defineemits,
  ref,
  onmounted,
  computed,
} from "vue";
interface props {
  list: string[]; // 数据源
  rowheight: number; // 每行的高度
  viewcount: number; // 显示数量
  loading: boolean; // 控制loading
}

const props = withdefaults(defineprops<props>(), {
  list: () => [],
  rowheight: 200,
  viewcount: 10,
  loading: false,
});

const emit = defineemits<{
  (e: "bottomload"): void;
}>();
let viewheight = ref(0); //可视区域的高度
let startindex = ref(0); //开始索引
let endindex = ref(0); //结束索引
let transformoffset = ref(0); //列表的偏移量
const viewport = ref(null);

onmounted(() => {
  initdata();
});
let showlist = computed(() =>
  props.list.slice(startindex.value, endindex.value)
); //展示的数据
let listheight = computed(() => props.list.length * props.rowheight); //列表的总高度

// 初始化一些数据
const initdata = () => {
  endindex.value = props.viewcount;
  viewheight.value = viewport.value.offsetheight;
};

// 列表滚动
const onscroll = () => {
  const scrolltop = viewport.value.scrolltop; // 获取试图往上滚动的高度
  const currentindex = math.floor(scrolltop / props.rowheight); // 计算当前的索引
  // 只在需要变化的时 才重新赋值
  if (startindex.value !== currentindex) {
    startindex.value = currentindex;
    endindex.value = startindex.value + props.viewcount; // 结束索引
    transformoffset.value = scrolltop - (scrolltop % props.rowheight);
  }
  // 触底了
  if (math.round(viewheight.value + scrolltop) === listheight.value) {
    // 发送触底加载事件
    emit("bottomload");
  }
};
</script>

三、完整代码

demo.vue

<template>
  <div class="page">
    <h3>长列表渲染</h3>
    <listscroll
      class="list_scroll"
      :list="listdata"
      :loading="isloading"
      @bottomload="onbottomload"
    >
      <template v-slot="{ record }">
        <div class="row_content" @click="handleclick(record)">
          <div>{{ record }}</div>
          <img
            class="image"
            src="https://gimg2.baidu.com/image_search/src=http%3a%2f%2fsafe-img.xhscdn.com%2fbw1%2f2076f7ae-d134-4dc4-a865-af1b2029d400%3fimageview2%2f2%2fw%2f1080%2fformat%2fjpg&refer=http%3a%2f%2fsafe-img.xhscdn.com&app=2002&size=f9999,10000&q=a80&n=0&g=0n&fmt=auto?sec=1680249943&t=7646a71b62c810256a2b414e96106808"
          />
        </div>
      </template>
    </listscroll>
  </div>
</template>

<script>
export default {
  data() {
    return {
      listdata: [], // 总数据
      isloading: false, // 展示loading
    };
  },
  mounted() {
    this.getlistdata();
  },
  methods: {
    // 获取数据
    getlistdata() {
      const count = 20 + this.listdata.length;
      const start = this.listdata.length;
      this.isloading = true;
      settimeout(() => {
        for (let i = start; i < count; i++) {
          this.listdata.push(i);
        }
        this.isloading = false;
      }, 500);
    },
    // 监听触底事件
    onbottomload() {
      console.log("触底了");
      if (this.listdata.length >= 100) {
        console.log("数据加载完了～");
        return;
      }
      // 加载数据
      this.getlistdata();
    },
    // 监听点击每行
    handleclick(record) {
      console.log(record, "record");
    },
  },
};
</script>

<style lang="less" scoped>
.page {
  display: flex;
  flex-direction: column;
  height: 100vh;
  .list_scroll {
    flex: 1;
  }
}
.row_content {
  width: 100%;
  height: 100%;
  .image {
    display: block;
    width: 100%;
    height: 160px;
    object-fit: cover;
  }
}
</style>

listscroll.vue

<template>
  <div class="viewport" ref="viewport" @scroll="onscroll">
    <!-- 滚动条 -->
    <div class="scrollbar" :style="{ height: listheight + 'px' }"></div>
    <!-- 展示的列表 -->
    <div
      class="list"
      :style="{ transform: `translatey(${transformoffset}px)` }"
    >
      <div
        class="row"
        :style="{ height: rowheight + 'px' }"
        v-for="(item, index) in showlist"
        :key="index"
      >
        <slot :record="item"></slot>
      </div>
    </div>
    <!-- 加载 -->
    <div class="loading_wrap" v-show="loading">
      <div class="loading">
        <div class="container"></div>
      </div>
      <div>正在加载中</div>
    </div>
  </div>
</template>

<script lang="ts" setup>
import {
  defineprops,
  withdefaults,
  defineemits,
  ref,
  onmounted,
  computed,
} from "vue";
interface props {
  list: string[]; // 数据源
  rowheight: number; // 每行的高度
  viewcount: number; // 显示数量
  loading: boolean; // 控制loading
}

const props = withdefaults(defineprops<props>(), {
  list: () => [],
  rowheight: 200,
  viewcount: 10,
  loading: false,
});

const emit = defineemits<{
  (e: "bottomload"): void;
}>();
let viewheight = ref(0); //可视区域的高度
let startindex = ref(0); //开始索引
let endindex = ref(0); //结束索引
let transformoffset = ref(0); //列表的偏移量
const viewport = ref(null);

onmounted(() => {
  initdata();
});
let showlist = computed(() =>
  props.list.slice(startindex.value, endindex.value)
); //展示的数据
let listheight = computed(() => props.list.length * props.rowheight); //列表的总高度

// 初始化一些数据
const initdata = () => {
  endindex.value = props.viewcount;
  viewheight.value = viewport.value.offsetheight;
};

// 列表滚动
const onscroll = () => {
  const scrolltop = viewport.value.scrolltop; // 获取试图往上滚动的高度
  const currentindex = math.floor(scrolltop / props.rowheight); // 计算当前的索引
  // 只在需要变化的时 才重新赋值
  if (startindex.value !== currentindex) {
    startindex.value = currentindex;
    endindex.value = startindex.value + props.viewcount; // 结束索引
    transformoffset.value = scrolltop - (scrolltop % props.rowheight);
  }
  // 触底了
  if (math.round(viewheight.value + scrolltop) === listheight.value) {
    // 发送触底加载事件
    emit("bottomload");
  }
};
</script>

<style lang="less" scoped>
/*
------最外层容器---------*/
.viewport {
  width: 100%;
  height: 100%; // 这个的高度让父组件去决定
  background-color: #fff;
  position: relative;
  overflow-y: auto;
}
/*
------列表展示层容器---------*/
.list {
  position: absolute;
  top: 0;
  left: 0;
  right: 0;
}
/*
------每行容器---------*/
.row {
  overflow: hidden;
}
/*
------loading样式---------*/
.loading_wrap {
  display: flex;
  justify-content: center;
  align-items: center;
  color: #999;
  padding: 20px 0;
  .loading {
    box-sizing: border-box;
    width: 20px;
    height: 20px;
    border: 2px solid #ddd;
    border-radius: 50%;
    animation: rotate 1s linear infinite;
    margin-right: 10px;
  }
  .container {
    position: relative;
    top: 50%;
    left: 50%;
    width: 10px;
    height: 10px;
    background-color: #fff;
  }
}
/*
------loading动画---------*/
@keyframes rotate {
  from {
    transform-origin: center center;
    transform: rotate(0deg);
  }
  to {
    transform-origin: center center;
    transform: rotate(360deg);
  }
}
</style>
