什么是websocket？

websocket是一种在单个tcp连接上进行全双工通信的协议。websocket通信协议于2011年被ietf定为标准rfc 6455，并由rfc7936补充规范。websocket api也被w3c定为标准。

websocket使得客户端和服务器之间的数据交换变得更加简单，允许服务端主动向客户端推送数据。在websocket api中，浏览器和服务器只需要完成一次握手，两者之间就直接可以创建持久性的连接，并进行双向数据传输。

为什么有了http协议还要websocket

http协议采用的是客户端（浏览器）轮询的方式，即客户端发送请求，服务端做出响应，为了获取最新的数据，需要不断的轮询发出http请求，占用大量带宽。
websocket采用了一些特殊的报头，使得浏览器和服务器只需要通过“握手”建立一条连接通道后，此链接保持活跃状态，之后的客户端和服务器的通信都使用这个连接，解决了web实时性的问题，相比于http有一下好处：

一个web客户端只建立一个tcp连接
websocket服务端可以主动推送（push）数据到web客户端
有更加轻量级的头，减少了数据传输量

特点

建立在tcp协议只上，服务端比较容易实现
于http协议有良好的兼容性，默认端口也是80和443，握手阶段使用http协议，因此握手时不容易屏蔽，能通过各种http代理服务器
数据格式轻量，通信高效且节省带宽
支持传输文本数据和二进制数据
没有同源限制，客户端可以与任意服务器通信
也支持加密传输，ws+ssl，url形如wss://

技术

jdk8
maven
springboot2.6.11
websocket
fastjosn

实现

pom.xml

<?xml version="1.0" encoding="utf-8"?>
<project xmlns="http://maven.apache.org/pom/4.0.0" xmlns:xsi="http://www.w3.org/2001/xmlschema-instance"
         xsi:schemalocation="http://maven.apache.org/pom/4.0.0 https://maven.apache.org/xsd/maven-4.0.0.xsd">
    <modelversion>4.0.0</modelversion>
    <parent>
        <groupid>org.springframework.boot</groupid>
        <artifactid>spring-boot-starter-parent</artifactid>
        <version>2.6.11</version>
        <relativepath/> <!-- lookup parent from repository -->
    </parent>
    <groupid>com.websocket</groupid>
    <artifactid>springboot_websocket</artifactid>
    <version>0.0.1-snapshot</version>
    <name>springboot_websocket</name>
    <description>springboot_websocket</description>
    <properties>
        <java.version>1.8</java.version>
    </properties>
    <dependencies>
        <dependency>
            <groupid>org.springframework.boot</groupid>
            <artifactid>spring-boot-starter-web</artifactid>
        </dependency>
        <dependency>
            <groupid>org.springframework.boot</groupid>
            <artifactid>spring-boot-starter-websocket</artifactid>
        </dependency>
        <dependency>
            <groupid>com.alibaba</groupid>
            <artifactid>fastjson</artifactid>
            <version>1.2.3</version>
        </dependency>
        <dependency>
            <groupid>org.springframework.boot</groupid>
            <artifactid>spring-boot-devtools</artifactid>
            <scope>runtime</scope>
            <optional>true</optional>
        </dependency>
        <dependency>
            <groupid>org.projectlombok</groupid>
            <artifactid>lombok</artifactid>
            <optional>true</optional>
        </dependency>
        <dependency>
            <groupid>org.springframework.boot</groupid>
            <artifactid>spring-boot-starter-test</artifactid>
            <scope>test</scope>
        </dependency>
    </dependencies>

    <build>
        <plugins>
            <plugin>
                <groupid>org.springframework.boot</groupid>
                <artifactid>spring-boot-maven-plugin</artifactid>
                <configuration>
                    <excludes>
                        <exclude>
                            <groupid>org.projectlombok</groupid>
                            <artifactid>lombok</artifactid>
                        </exclude>
                    </excludes>
                </configuration>
            </plugin>
        </plugins>
    </build>

</project>

websocket核心配置

package com.websocket.springboot_websocket.config;

import org.springframework.context.annotation.bean;
import org.springframework.context.annotation.configuration;
import org.springframework.web.socket.server.standard.serverendpointexporter;

/**
 * @program: springboot_websocket
 * @classname websocketconfig
 * @author: liutao
 * @description: websocket配置类
 * @create: 2022-08-19 18:42
 * @version 1.0
 **/
@configuration
public class websocketconfig {
    @bean
    public serverendpointexporter serverendpointexporter() {
        return new serverendpointexporter();
    }
}

配置websocket服务

package com.websocket.springboot_websocket.websocket;

import lombok.extern.slf4j.slf4j;
import org.springframework.stereotype.component;

import javax.websocket.*;
import javax.websocket.server.pathparam;
import javax.websocket.server.serverendpoint;
import java.util.arraylist;
import java.util.collections;
import java.util.list;
import java.util.concurrent.concurrenthashmap;
import java.util.concurrent.copyonwritearrayset;

/**
 * @program: springboot_websocket
 * @classname websocketserver
 * @author: liutao
 * @description: websocket服务
 * @create: 2022-08-19 18:52
 * @version 1.0
 **/
@slf4j
@component
@serverendpoint("/websocket/{userid}")
public class websocketserver {
//    在线人数
    private static int onlinecount;
//    当前会话
    private session session;
//    用户唯一标识
    private string userid;

    private static copyonwritearrayset<websocketserver> websocketset = new copyonwritearrayset<>();

    /**
     * concurrent包的线程安全set，用来存放每个客户端对应的mywebsocket对象
     */
    private static concurrenthashmap<string,websocketserver> websocketmap = new concurrenthashmap();

    /**
     * 为了保存在线用户信息，在方法中新建一个list存储一下【实际项目依据复杂度，可以存储到数据库或者缓存】
     */
    private final static list<session> sessions = collections.synchronizedlist(new arraylist<>());

 /**
  * @methodname: onopen
  * @description: 建立连接
  * @author liutao
  * @param  [session, userid]
  * @updatetime 2022/8/19 19:31
  * @return void
  * @throws
  **/
 @onopen
    public void onopen(session session, @pathparam("userid") string userid) {
        this.session = session;
        this.userid = userid;
        websocketset.add(this);
        sessions.add(session);
        if (websocketmap.containskey(userid)) {
            websocketmap.remove(userid);
            websocketmap.put(userid,this);
        } else {
            websocketmap.put(userid,this);
            addonlinecount();
        }
        log.info("[连接id:{}] 建立连接, 当前连接数:{}", this.userid, getonlinecount());
    }

   /**
    * @methodname: onclose
    * @description: 断开连接
    * @author liutao
    * @param  []
    * @updatetime 2022/8/19 19:31
    * @return void
    * @throws
    **/
   @onclose
    public void onclose() {
        websocketset.remove(this);
        if (websocketmap.containskey(userid)) {
            websocketmap.remove(userid);
            subonlinecount();
        }
        log.info("[连接id:{}] 断开连接, 当前连接数:{}", userid, getonlinecount());
    }

    /**
     * @methodname: onerror
     * @description: 发送错误
     * @author liutao
     * @param  [session, error]
     * @updatetime 2022/8/19 19:32
     * @return void
     * @throws
     **/
    @onerror
    public void onerror(session session, throwable error) {
        log.info("[连接id:{}] 错误原因:{}", this.userid, error.getmessage());
        error.printstacktrace();
    }

   /**
    * @methodname: onmessage
    * @description: 收到消息
    * @author liutao
    * @param  [message]
    * @updatetime 2022/8/19 19:32
    * @return void
    * @throws
    **/
   @onmessage
    public void onmessage(string message) {
        log.info("[连接id:{}] 收到消息:{}", this.userid, message);
    }

    /**
     * @methodname: sendmessage
     * @description: 发送消息
     * @author liutao
     * @param  [message, userid]
     * @updatetime 2022/8/19 19:32
     * @return void
     * @throws
     **/
    public void sendmessage(string message,long userid) {
        websocketserver websocketserver = websocketmap.get(string.valueof(userid));
        if (websocketserver!=null){
            log.info("【websocket消息】推送消息,[touser]userid={},message={}", userid,message);
            try {
                websocketserver.session.getbasicremote().sendtext(message);
            } catch (exception e) {
                e.printstacktrace();
                log.error("[连接id:{}] 发送消息失败, 消息:{}", this.userid, message, e);
            }
        }
    }

    /**
     * @methodname: sendmassmessage
     * @description: 群发消息
     * @author liutao
     * @param  [message]
     * @updatetime 2022/8/19 19:33
     * @return void
     * @throws
     **/
    public void sendmassmessage(string message) {
        try {
            for (session session : sessions) {
                if (session.isopen()) {
                    session.getbasicremote().sendtext(message);
                    log.info("[连接id:{}] 发送消息:{}",session.getrequestparametermap().get("userid"),message);
                }
            }
        } catch (exception e) {
            e.printstacktrace();
        }
    }

    /**
     * 获取当前连接数
     * @return
     */
    public static synchronized int getonlinecount() {
        return onlinecount;
    }

    /**
     * 当前连接数加一
     */
    public static synchronized void addonlinecount() {
        websocketserver.onlinecount++;
    }

    /**
     * 当前连接数减一
     */
    public static synchronized void subonlinecount() {
        websocketserver.onlinecount--;
    }

}

web接口

package com.websocket.springboot_websocket.web;


import com.alibaba.fastjson.jsonobject;
import com.websocket.springboot_websocket.websocket.websocketserver;
import lombok.data;
import lombok.experimental.accessors;
import org.springframework.beans.factory.annotation.autowired;
import org.springframework.web.bind.annotation.getmapping;
import org.springframework.web.bind.annotation.pathvariable;
import org.springframework.web.bind.annotation.requestmapping;
import org.springframework.web.bind.annotation.restcontroller;

/**
 * @program: springboot_websocket
 * @classname websocketcontroller
 * @author: liutao
 * @description: websocket web层
 * @create: 2022-08-19 19:01
 * @version 1.0
 **/
@restcontroller
@requestmapping("/ws")
public class websocketcontroller {
    @autowired
    private websocketserver websocketserver;

    /**
     * 消息发送
     */
    @getmapping("/send/{userid}/{msg}")
    public void send(@pathvariable string msg, @pathvariable string userid){
            websocketserver.sendmessage(jsonobject.tojsonstring(msg), long.valueof(string.valueof(userid)));
    }

    /**
     * 群发消息测试(给当前连接用户发送)
     */
    @getmapping("/sendmassmessage")
    public void sendmassmessage(){
        websocketresponse response = new websocketresponse();
        response.settitle("群发主题");
        websocketserver.sendmassmessage(jsonobject.tojsonstring(response));
    }

    @data
    @accessors(chain = true)
    public static class websocketresponse {
        private string title;
        private string userid;
        private string username;
        private int age;
    }

}
