Vue3实现canvas画布组件自定义画板实例代码

<template>
  <div>
    <div class="toolbar">
      <el-color-picker v-model="currentcolor" />
      <el-slider v-model="currentlinewidth" :min="1" :max="10" />
      <el-button :class="{ 'active': currenttool === 'brush' }" @click="selecttool('brush')">画笔</el-button>
      <el-button :class="{ 'active': currenttool === 'eraser' }" @click="selecttool('eraser')">橡皮擦</el-button>
      <el-slider v-if="currenttool === 'eraser'" v-model="erasersize" :min="10" :max="100" />
      <el-button :class="{ 'active': currenttool === 'rectangle' }" @click="selecttool('rectangle')">长方形</el-button>
      <el-button :class="{ 'active': currenttool === 'circle' }" @click="selecttool('circle')">圆形</el-button>
      <el-slider v-if="currenttool === 'check' || currenttool === 'cross' || currenttool === 'arrow'"
        v-model="shapesize" :min="10" :max="100" />
      <el-button :class="{ 'active': currenttool === 'check' }" @click="selecttool('check')">打√</el-button>
      <el-button :class="{ 'active': currenttool === 'cross' }" @click="selecttool('cross')">打×</el-button>
      <el-button :class="{ 'active': currenttool === 'arrow' }" @click="selecttool('arrow')">箭头</el-button>
      <el-button :class="{ 'active': currenttool === 'text' }" @click="selecttool('text')">文本</el-button>
      <el-button @click="clearcanvas">清除</el-button>
      <el-button @click="savecanvas">保存</el-button>
      <el-button @click="undo">撤销</el-button>
      <el-button @click="redo">重做</el-button>
      <el-button @click="rotatecanvas">翻转</el-button>
      <el-button @click="zoomin">放大</el-button>
      <el-button @click="zoomout">缩小</el-button>

    </div>
    <div class="canvas-container">
      <canvas ref="bgcanvas" width="800" height="600" style="position: absolute;"></canvas>
      <canvas ref="drawcanvas" width="800" height="600" style="position: absolute;"></canvas>
      <canvas ref="shapecanvas" @mousedown="handleclick" @mousemove="draw" @mouseup="stopdrawing"
        @mouseout="stopdrawing" width="800" height="600" style="position: absolute; border: 1px solid #000;"></canvas>
      <textarea v-if="currenttool === 'text'" v-model="textcontent" :style="[textstyle, { color: currentcolor }]"
        @blur="finishtextediting" @input="updatetextcontent" ref="textarea" class="text-editor"
        placeholder="请输入文本"></textarea>
    </div>
  </div>
</template>

<script setup>
import { ref, reactive, onmounted, watch } from 'vue';

const props = defineprops({
  imageurl: {
    type: string,
    required: true,
  },
});

const bgcanvas = ref(null);
const drawcanvas = ref(null);
const shapecanvas = ref(null);
const bgcontext = ref(null);
const drawcontext = ref(null);
const shapecontext = ref(null);
const drawing = ref(false);
const currentcolor = ref('#e81e1e');
const currentlinewidth = ref(2);
const currenttool = ref('brush');
const erasersize = ref(20);
const history = reactive({
  undostack: [],
  redostack: [],
});
const shapes = ref([]);
const textshapes = ref([]); // 用于保存文本形状
const activeshape = ref(null);
const shapesize = ref(30);
const textcontent = ref('');
const textarea = ref(null);
const textstyle = reactive({
  position: 'absolute',
  border: '1px dashed black',
  backgroundcolor: 'rgba(255, 255, 255, 0)',
  resize: 'none',
  width: '200px',
  height: '100px',
  zindex: 10,
  display: 'none',
});
const rotation = ref(0);
const zoomfactor = ref(1); // 当前缩放比例
const rotatecanvas = () => {
  rotation.value = (rotation.value + 90) % 360;
  redrawcanvas();
};

const redrawcanvas = () => {
  clearallcanvases();
  drawimage();
  redrawshapecanvas();
};


const clearallcanvases = () => {
  drawcontext.value.clearrect(0, 0, drawcanvas.value.width, drawcanvas.value.height);
  shapecontext.value.clearrect(0, 0, shapecanvas.value.width, shapecanvas.value.height);
};

const savestate = () => {
  try {
    const state = {
      draw: drawcanvas.value.todataurl(),
      shapes: shapes.value.map(shape => ({ ...shape })),
      textshapes: textshapes.value.map(text => ({ ...text })),
      rotation: rotation.value,
    };
    history.undostack.push(state);
    history.redostack = [];
  } catch (e) {
    console.error('cannot save canvas state:', e);
  }
};


const restorestate = (state) => {
  drawcontext.value.clearrect(0, 0, drawcanvas.value.width, drawcanvas.value.height);
  shapecontext.value.clearrect(0, 0, shapecanvas.value.width, shapecanvas.value.height);

  const img = new image();
  img.src = state.draw;
  img.onload = () => {
    drawcontext.value.drawimage(img, 0, 0);
    shapes.value = state.shapes;
    textshapes.value = state.textshapes;
    rotation.value = state.rotation;
    redrawcanvas();  // 调用自定义的重绘函数以应用旋转
  };
};


const handleclick = (event) => {
  const { offsetx, offsety } = event;

  if (currenttool.value === 'text') {
    textstyle.left = `${offsetx}px`;
    textstyle.top = `${offsety}px`;
    textstyle.display = 'block';
    textarea.value.focus();
  } else if (['check', 'cross'].includes(currenttool.value)) {
    const shape = {
      type: currenttool.value,
      color: currentcolor.value,
      linewidth: currentlinewidth.value,
      startx: offsetx,
      starty: offsety,
      width: shapesize.value,
      height: shapesize.value,
    };
    shapes.value.push(shape);
    drawshape(shape);
    savestate();
  } else {
    startdrawing(event);
  }
};

const startdrawing = (event) => {
  drawing.value = true;
  const { offsetx, offsety } = event;

  if (currenttool.value === 'brush') {
    drawcontext.value.linewidth = currentlinewidth.value;
    drawcontext.value.strokestyle = currentcolor.value;
    drawcontext.value.beginpath();
    drawcontext.value.moveto(offsetx, offsety);
  } else if (['arrow', 'rectangle', 'circle'].includes(currenttool.value)) {
    const shape = {
      type: currenttool.value,
      color: currentcolor.value,
      linewidth: currentlinewidth.value,
      startx: offsetx,
      starty: offsety,
      width: 0,
      height: 0,
    };
    shapes.value.push(shape);
    activeshape.value = shape;
  }
};

const draw = (event) => {
  if (!drawing.value) return;

  const { offsetx, offsety } = event;

  if (currenttool.value === 'brush') {
    drawcontext.value.lineto(offsetx, offsety);
    drawcontext.value.stroke();
  } else if (currenttool.value === 'eraser') {
    const x = offsetx - erasersize.value / 2;
    const y = offsety - erasersize.value / 2;
    drawcontext.value.clearrect(x, y, erasersize.value, erasersize.value);
  } else if (['rectangle', 'circle', 'arrow'].includes(currenttool.value)) {
    if (activeshape.value) {
      activeshape.value.width = offsetx - activeshape.value.startx;
      activeshape.value.height = offsety - activeshape.value.starty;
      redrawshapecanvas();
    }
  }
};

const stopdrawing = () => {
  if (drawing.value) {
    if (currenttool.value === 'brush') {
      drawcontext.value.closepath();
    }
    savestate();
    drawing.value = false;
    activeshape.value = null;
  }
};

const clearcanvas = () => {
  drawcontext.value.clearrect(0, 0, drawcanvas.value.width, drawcanvas.value.height);
  shapecontext.value.clearrect(0, 0, shapecanvas.value.width, shapecanvas.value.height);
  shapes.value = [];
  textshapes.value = [];
  savestate();
};

const savecanvas = () => {
  const link = document.createelement('a');
  link.download = 'drawing.png';

  const combinedcanvas = document.createelement('canvas');
  combinedcanvas.width = drawcanvas.value.width;
  combinedcanvas.height = drawcanvas.value.height;
  const combinedcontext = combinedcanvas.getcontext('2d');

  combinedcontext.drawimage(bgcanvas.value, 0, 0);
  combinedcontext.drawimage(drawcanvas.value, 0, 0);
  combinedcontext.drawimage(shapecanvas.value, 0, 0);

  link.href = combinedcanvas.todataurl();
  link.click();
};

const selecttool = (tool) => {
  currenttool.value = tool;
  if (tool === 'eraser') {
    updateerasercursor();
  } else {
    shapecanvas.value.style.cursor = tool === 'brush' ? 'crosshair' : 'default';
  }
};

const updateerasercursor = () => {
  shapecanvas.value.style.cursor = `url('${cursorurl}') ${erasersize.value / 2} ${erasersize.value / 2}, auto`;
};

const undo = () => {
  if (history.undostack.length > 0) {
    const laststate = history.undostack.pop();
    history.redostack.push({
      draw: drawcanvas.value.todataurl(),
      shapes: shapes.value.map(shape => ({ ...shape })),
      textshapes: textshapes.value.map(text => ({ ...text })),
      rotation: rotation.value,
    });
    restorestate(laststate);
  }
};

const redo = () => {
  if (history.redostack.length > 0) {
    const laststate = history.redostack.pop();
    history.undostack.push({
      draw: drawcanvas.value.todataurl(),
      shapes: shapes.value.map(shape => ({ ...shape })),
      textshapes: textshapes.value.map(text => ({ ...text })),
      rotation: rotation.value,
    });
    restorestate(laststate);
  }
};
const zoomin = () => {
  zoomfactor.value *= 1.1; // 放大10%
  redrawcanvas();
};

const zoomout = () => {
  zoomfactor.value /= 1.1; // 缩小10%
  redrawcanvas();
};

const drawimage = () => {
  if (props.imageurl) {
    const img = new image();
    img.crossorigin = 'anonymous'; // 处理跨域图片
    img.src = props.imageurl;
    img.onload = () => {
      const padding = 30; // 设置留白区域的大小
      bgcontext.value.clearrect(0, 0, bgcanvas.value.width, bgcanvas.value.height);
      bgcontext.value.save();
      bgcontext.value.translate(padding, padding); // 在绘制时增加留白
      // bgcontext.value.drawimage(img, 0, 0, bgcanvas.value.width - 2 * padding, bgcanvas.value.height - 2 * padding);
      bgcontext.value.translate(bgcanvas.value.width / 2, bgcanvas.value.height / 2);
      bgcontext.value.rotate((rotation.value * math.pi) / 180);
      bgcontext.value.scale(zoomfactor.value, zoomfactor.value); // 应用缩放
      // bgcontext.value.drawimage(img, -bgcanvas.value.width / 2, -bgcanvas.value.height / 2, bgcanvas.value.width, bgcanvas.value.height);
      bgcontext.value.drawimage(img, -bgcanvas.value.width / 2, -bgcanvas.value.height / 2, bgcanvas.value.width - 2 * padding, bgcanvas.value.height - 2 * padding);
      bgcontext.value.restore();
    };
  }
};


const redrawshapecanvas = () => {
  shapecontext.value.clearrect(0, 0, shapecanvas.value.width, shapecanvas.value.height);
  shapes.value.foreach(shape => {
    drawshape(shape);
  });
  textshapes.value.foreach(text => {
    drawshape(text);
  });
};

const drawshape = (shape) => {
  shapecontext.value.beginpath();
  shapecontext.value.strokestyle = shape.color;
  shapecontext.value.linewidth = shape.linewidth;

  if (shape.type === 'rectangle') {
    shapecontext.value.rect(shape.startx, shape.starty, shape.width, shape.height);
  } else if (shape.type === 'circle') {
    shapecontext.value.arc(shape.startx, shape.starty, math.sqrt(math.pow(shape.width, 2) + math.pow(shape.height, 2)), 0, 2 * math.pi);
  } else if (shape.type === 'check') {
    shapecontext.value.beginpath();
    shapecontext.value.moveto(shape.startx, shape.starty);
    shapecontext.value.lineto(shape.startx + shape.width, shape.starty + shape.height / 2);
    shapecontext.value.lineto(shape.startx + shape.width * 2, shape.starty - shape.height);
    shapecontext.value.stroke();
  } else if (shape.type === 'cross') {
    shapecontext.value.beginpath();
    shapecontext.value.moveto(shape.startx, shape.starty);
    shapecontext.value.lineto(shape.startx + shape.width, shape.starty + shape.height);
    shapecontext.value.moveto(shape.startx, shape.starty + shape.height);
    shapecontext.value.lineto(shape.startx + shape.width, shape.starty);
    shapecontext.value.stroke();
  } else if (shape.type === 'arrow') {
    const headlength = 10;
    const angle = math.atan2(shape.height, shape.width);
    shapecontext.value.moveto(shape.startx, shape.starty);
    shapecontext.value.lineto(shape.startx + shape.width, shape.starty + shape.height);
    shapecontext.value.lineto(shape.startx + shape.width - headlength * math.cos(angle - math.pi / 6), shape.starty + shape.height - headlength * math.sin(angle - math.pi / 6));
    shapecontext.value.moveto(shape.startx + shape.width, shape.starty + shape.height);
    shapecontext.value.lineto(shape.startx + shape.width - headlength * math.cos(angle + math.pi / 6), shape.starty + shape.height - headlength * math.sin(angle + math.pi / 6));
  } else if (shape.type === 'text') {
    shapecontext.value.fillstyle = shape.color;
    shapecontext.value.font = '16px arial';
    shapecontext.value.textalign = 'left';
    shapecontext.value.textbaseline = 'top';
    shapecontext.value.filltext(shape.content, shape.startx, shape.starty);
  }

  shapecontext.value.stroke();
};

const finishtextediting = () => {
  if (textcontent.value.trim() === '') return;
  const { offsetleft, offsettop, offsetwidth, offsetheight } = textarea.value;
  const shape = {
    type: 'text',
    content: textcontent.value,
    color: currentcolor.value,
    startx: offsetleft,
    starty: offsettop,
    width: offsetwidth,
    height: offsetheight,
  };
  textshapes.value.push(shape);
  redrawshapecanvas();
  textcontent.value = '';
  textstyle.display = 'none';
};

const updatetextcontent = () => {
  // optional: handle text content updates here if needed
};

onmounted(() => {
  bgcontext.value = bgcanvas.value.getcontext('2d');
  drawcontext.value = drawcanvas.value.getcontext('2d');
  shapecontext.value = shapecanvas.value.getcontext('2d');
  drawimage();
  savestate();
});

watch(() => props.imageurl, drawimage);
watch(() => erasersize.value, updateerasercursor);
</script>

<style scoped>
.toolbar {
  margin-bottom: 10px;
}

.canvas-container {
  position: relative;
  /* width: 800px;
  height: 600px; */
}

canvas {
  cursor: default;
  /* border: 1px solid #ccc; */
  /* padding: 20px; */
}

.text-editor {
  display: none;
  /* hidden initially */
}

.el-button.active {
  background-color: #409eff;
  color: white;
}

.text-editor {
  display: block;
  position: absolute;
  border: 2px solid #ddd;
  border-radius: 4px;
  background-color: #f9f9f9;
  font-size: 14px;
  padding: 10px;
  resize: none;
  box-shadow: 0 2px 4px rgba(0, 0, 0, 0.1);
  z-index: 10;
  transition: border-color 0.3s ease;
  width: 200px;
  height: 100px;
  top: 0;
  left: 0;
}

.text-editor:focus {
  border-color: #409eff;
  outline: none;
}

.text-editor::placeholder {
  color: #888;
  font-style: italic;
}
</style>
