我要评论一.概要
此项目将围绕一个时间序列预测任务展开。该任务是kaggle上的一个比赛，m5 forecasting - accuarcy（https://www.kaggle.com/c/m5-forecasting-accuracy/notebooks ）。m5的赛题目标是预测沃尔玛各种商品在未来28天的销量。本案例使用前1913天的数据作为训练数据，来预测1914天到1941天的销量。并且，我们只对最细粒度的30490条序列进行预测。 训练数据从kaggle中自行下载：
- calendar.csv - contains information about the dates on which the products are sold.
- sales_train_validation.csv - contains the historical daily unit sales data per product and store [d_1 - d_1913]
- sample_submission.csv - the correct format for submissions. reference the evaluation tab for more info.
- sell_prices.csv - contains information about the price of the products sold per store and date.
- sales_train_evaluation.csv - includes sales [d_1 - d_1941] (labels used for the public leaderboard)
以上数据下载后放入resources/advanced下，并在properties.properties中配置一下文件名和路径，以供程序读取和处理数据。
1.数据处理以及特征工程利用java spark进行提取，见timeseries.java。
2.模型的训练及预测利用python lightgbm进行操作，见time_series.ipynb，data.7z下是spark处理好的数据。
二.特征工程代码解读，完整见项目中代码注释
/**
* 分析和挖掘数据
* @param session
*/
public static void analysisdata(sparksession session) {
// 一.数据集
/* 1.这里是历史销量sales_train_validation数据
+--------------------+-------------+---------+-------+--------+--------+---+---+---+---+---+---+---+---+-
| id| item_id| dept_id| cat_id|store_id|state_id|d_1|d_2|d_3|d_4|d_5|d_6|d_7|d_8|d_9|d_10|...
+--------------------+-------------+---------+-------+--------+--------+---+---+---+---+---+---+---+---+---+----+
|hobbies_1_001_ca_...|hobbies_1_001|hobbies_1|hobbies| ca_1| ca| 0| 0| 0| 0| 0| 0| 0| 0| 0| 0|...
|hobbies_1_002_ca_...|hobbies_1_002|hobbies_1|hobbies| ca_1| ca| 0| 0| 0| 0| 0| 0| 0| 0| 0| 0|...
|hobbies_1_003_ca_...|hobbies_1_003|hobbies_1|hobbies| ca_1| ca| 0| 0| 0| 0| 0| 0| 0| 0| 0| 0|...
+--------------------+-------------+---------+-------+--------+--------+---+---+---+---+---+---+---+---+---+----+
schema:
|-- id: string (nullable = true)
|-- item_id: string (nullable = true)
|-- dept_id: string (nullable = true)
|-- cat_id: string (nullable = true)
|-- store_id: string (nullable = true)
|-- state_id: string (nullable = true)
|-- d_1: integer (nullable = true)
|-- d_2: integer (nullable = true)
|-- d_3: integer (nullable = true)
|-- d_4: integer (nullable = true)
|-- ......
*/
string salestrainvalidationpath = timeseries.class.getclassloader().getresource(propertiesreader.get("advanced_timeseries_sales_train_validation_csv")).getpath().replacefirst("/", "");
dataset<row> salestvdataset = session.read()
.option("sep", ",")
.option("header", true)
.option("inferschema", true)
.csv(salestrainvalidationpath);
/*首先，我们只留下salestvdataset中的历史特征值，删去其他列。
+---+---+---+---+---+---+---+---+---+----+
|d_1|d_2|d_3|d_4|d_5|d_6|d_7|d_8|d_9|d_10|
+---+---+---+---+---+---+---+---+---+----+
| 0| 0| 0| 0| 0| 0| 0| 0| 0| 0|...
| 0| 0| 0| 0| 0| 0| 0| 0| 0| 0|...
| 0| 0| 0| 0| 0| 0| 0| 0| 0| 0|...
+---+---+---+---+---+---+---+---+---+----+
*/
column[] columns = new column[1913];
int index = 0;
for(string column : salestvdataset.columns()) {
if(column.contains("d_")) {
columns[index] = functions.col(column);
index++;
}
}
dataset<row> xdataset = salestvdataset.select(columns);
/* 2.这里是日历信息calendar数据
+----------+--------+--------+----+-----+----+---+------------+------------+------------+------------+-------+-------+-------+
| date|wm_yr_wk| weekday|wday|month|year| d|event_name_1|event_type_1|event_name_2|event_type_2|snap_ca|snap_tx|snap_wi|
+----------+--------+--------+----+-----+----+---+------------+------------+------------+------------+-------+-------+-------+
|2011-01-29| 11101|saturday| 1| 1|2011|d_1| null| null| null| null| 0| 0| 0|
|2011-01-30| 11101| sunday| 2| 1|2011|d_2| null| null| null| null| 0| 0| 0|
|2011-01-31| 11101| monday| 3| 1|2011|d_3| null| null| null| null| 0| 0| 0|
+----------+--------+--------+----+-----+----+---+------------+------------+------------+------------+-------+-------+-------+
schema:
|-- date: string (nullable = true)
|-- wm_yr_wk: integer (nullable = true)
|-- weekday: string (nullable = true)
|-- wday: integer (nullable = true)
|-- month: integer (nullable = true)
|-- year: integer (nullable = true)
|-- d: string (nullable = true)
|-- event_name_1: string (nullable = true)
|-- event_type_1: string (nullable = true)
|-- event_name_2: string (nullable = true)
|-- event_type_2: string (nullable = true)
|-- snap_ca: integer (nullable = true)
|-- snap_tx: integer (nullable = true)
|-- snap_wi: integer (nullable = true)
*/
string calendarpath = timeseries.class.getclassloader().getresource(propertiesreader.get("advanced_timeseries_calendar_csv")).getpath().replacefirst("/", "");
dataset<row> calendardataset = session.read()
.option("sep", ",")
.option("header", true)
.option("inferschema", true)
.csv(calendarpath);
/* 3.商品每周的价格信息sell_prices
+--------+-------------+--------+----------+
|store_id| item_id|wm_yr_wk|sell_price|
+--------+-------------+--------+----------+
| ca_1|hobbies_1_001| 11325| 9.58|
| ca_1|hobbies_1_001| 11326| 9.58|
| ca_1|hobbies_1_001| 11327| 8.26|
+--------+-------------+--------+----------+
schema:
|-- store_id: string (nullable = true)
|-- item_id: string (nullable = true)
|-- wm_yr_wk: integer (nullable = true)
|-- sell_price: double (nullable = true)
*/
// string sellpricespath = timeseries.class.getclassloader().getresource(propertiesreader.get("advanced_timeseries_sell_prices_csv")).getpath().replacefirst("/", "");
// dataset<row> sellpricesdataset = session.read()
// .option("sep", ",")
// .option("header", true)
// .option("inferschema", true)
// .csv(sellpricespath);
// (1).测试集,我们只是计算了第1914天的数据的特征。这只些特征只能用来预测1914天的销量，也就是说，实际上是我们的测试数据。
int targetday = 1914;
// 使用历史数据中最后的7天构造特征
int localrange = 7;
// 由于使用前1913天的数据预测第1914天，历史数据与预测目标的距离只有1天，因此predictdistance=1
// 如果使用前1913天的数据预测第1915天，则历史数据与预测目标的距离有2天，因此predictdistance=2，以此类推
int predictdistance = 1;
dataset<row> testdataset = gettestdataset(salestvdataset, calendardataset, xdataset, targetday, predictdistance);
// (2).训练集,为了构造训练数据，我们对1914天之前的日期进行同样的特征计算操作，并附上它们的当天销量作为数据标签。
int trainingdatadays = 7; // 为了简便，现只取7天的数据作训练集
dataset<row> traindataset = gettraindataset(salestvdataset, calendardataset, xdataset, trainingdatadays, targetday, predictdistance);
string salestrainevaluationpath = timeseries.class.getclassloader().getresource(propertiesreader.get("advanced_timeseries__sales_train_evaluation_csv")).getpath().replacefirst("/", "");
dataset<row> labeldataset = session.read()
.option("sep", ",")
.option("header", true)
.option("inferschema", true)
.csv(salestrainevaluationpath);
// (3).测试集的label
dataset<row> testlabeldataset = gettestdatasetlabel(labeldataset, targetday);
// (4).训练集的label
dataset<row> trainlabeldataset = gettraindatasetlabel(labeldataset, targetday, trainingdatadays, predictdistance);
// (5).保存为csv文件，供python lightgbm训练
// 保存test dataset
string testdatasetcsvpath = "e:\\idea_project\\spark_data_mining\\src\\main\\resources\\dataalgorithms\\advanced\\timeseries_data\\testdata.csv";
savecsv(testdataset, testdataset.columns(), testdatasetcsvpath);
// 保存train dataset
string traindatasetcsvpath = "e:\\idea_project\\spark_data_mining\\src\\main\\resources\\dataalgorithms\\advanced\\timeseries_data\\traindata.csv";
savecsv(traindataset, traindataset.columns(), traindatasetcsvpath);
// 保存test label
string testlabelcsvpath = "e:\\idea_project\\spark_data_mining\\src\\main\\resources\\dataalgorithms\\advanced\\timeseries_data\\testlabel.csv";
savecsv(testlabeldataset, testlabeldataset.columns(), testlabelcsvpath);
// 保存train label
string trainlabelcsvpath = "e:\\idea_project\\spark_data_mining\\src\\main\\resources\\dataalgorithms\\advanced\\timeseries_data\\trainlabel.csv";
savecsv(trainlabeldataset, trainlabeldataset.columns(), trainlabelcsvpath);
}三.模型训练
