C#属性显示的实现示例

<window x:class="flowchart.mainwindow"
        xmlns="http://schemas.microsoft.com/winfx/2006/xaml/presentation"
        xmlns:x="http://schemas.microsoft.com/winfx/2006/xaml"
        xmlns:d="http://schemas.microsoft.com/expression/blend/2008"
        xmlns:mc="http://schemas.openxmlformats.org/markup-compatibility/2006"
        xmlns:local="clr-namespace:flowchart"
        mc:ignorable="d"
        title="mainwindow" height="450" width="800">
    <dockpanel>
        <stackpanel dockpanel.dock="left" width="300" margin="0 0 10 0">
            <stackpanel margin="0 10 0 10">
                <textblock text="属性" fontweight="bold" margin="0 0 0 10"/>
                <local:propertiesview x:name="_propertiesview" height="200"/>
            </stackpanel>
        </stackpanel>
        <border borderbrush="black" borderthickness="1"></border>
    </dockpanel>
</window>

using system;
using system.collections.generic;
using system.componentmodel;
using system.linq;
using system.text;
using system.threading.tasks;
using system.windows;
using system.windows.controls;
using system.windows.data;
using system.windows.documents;
using system.windows.input;
using system.windows.media;
using system.windows.media.imaging;
using system.windows.navigation;
using system.windows.shapes;

namespace flowchart
{
    /// <summary>
    /// mainwindow.xaml 的交互逻辑
    /// </summary>
    public partial class mainwindow : window
    {
        public mainwindow()
        {
            initializecomponent();
            datainitialize();
        }

        public list<selection> selections=new list<selection>();
        public void datainitialize()
        {
            selection selection = new selection();
            selection.location=new point(0,0);
            selection.size=new size(200,200);
            //selection.name = "测试";
            _propertiesview.selectedobject= selection;
        }
    }

    public class selection:inotifypropertychanged
    {
        private point _location;
        public point location
        {
            get { return _location; }
            set
            {
                _location = value;
                onpropertychanged("location");
            }
        }

        private size _size;
        //[browsable(false)]
        public size size
        {
            get { return _size; }
            set
            {
                _size = value;
                onpropertychanged("size");
            }
        }

        private string _name="test";

        public string name
        {
            get { return _name; }
            //set { _name = value;
            //    onpropertychanged("name");
            //}
        }


        public override string tostring()
        {
            return gettype().name;
        }

        public event propertychangedeventhandler propertychanged;

        protected void onpropertychanged(string name)
        {
            if (propertychanged != null)
                propertychanged(this, new propertychangedeventargs(name));
        }
    }
}

<usercontrol x:class="flowchart.propertiesview"
             xmlns="http://schemas.microsoft.com/winfx/2006/xaml/presentation"
             xmlns:x="http://schemas.microsoft.com/winfx/2006/xaml"
             xmlns:mc="http://schemas.openxmlformats.org/markup-compatibility/2006"
             xmlns:d="http://schemas.microsoft.com/expression/blend/2008"
             xmlns:local="clr-namespace:flowchart"
             mc:ignorable="d"
             d:designheight="450" d:designwidth="300">
    <usercontrol.resources>
        <controltemplate x:key="validationerrortemplate">
            <dockpanel>
                <image source="resources\empty.png" height="16" width="16" dockpanel.dock="right" margin="-18 0 0 0"
                       tooltip="{binding elementname=adorner,path=adornedelement.(validation.errors)[0].errorcontent}">
                </image>
                <adornedelementplaceholder x:name="adorner"/>
            </dockpanel>
        </controltemplate>

        <style x:key="gridlinestyle" targettype="line">
            <setter property="stroke" value="gray" />
            <setter property="stretch" value="fill" />
            <setter property="grid.zindex" value="1000" />
        </style>

        <style x:key="gridhorizontallinestyle" targettype="line" basedon="{staticresource gridlinestyle}">
            <setter property="x2" value="1" />
            <setter property="verticalalignment" value="bottom" />
            <setter property="grid.columnspan"
                value="{binding
                            path=columndefinitions.count,
                            relativesource={relativesource ancestortype=grid}}"/>
        </style>

        <style x:key="gridverticallinestyle" targettype="line" basedon="{staticresource gridlinestyle}">
            <setter property="y2" value="1" />
            <setter property="horizontalalignment" value="right" />
            <setter property="grid.rowspan"
                value="{binding
                            path=rowdefinitions.count,
                            relativesource={relativesource ancestortype=grid}}"/>
        </style>
    </usercontrol.resources>

    <border borderthickness="1" borderbrush="black">
        <dockpanel x:name="_panel">
            <border x:name="_label" width="50" height="16">
                <textblock text="empty" textalignment="center" foreground="gray"/>
            </border>
            <scrollviewer x:name="_gridcontainer" verticalscrollbarvisibility="auto">
                <grid x:name="_grid">
                    <grid.columndefinitions>
                        <columndefinition/>
                        <columndefinition/>
                    </grid.columndefinitions>

                    <line name="_vline" grid.column="0" grid.rowspan="1000" style="{staticresource gridverticallinestyle}"/>
                    <gridsplitter name="_splitter" grid.rowspan="1000"  margin="0,0,-2,0" width="4"
                                  background="white" opacity="0.01" grid.zindex="10000"/>

                </grid>
            </scrollviewer>
        </dockpanel>
    </border>
</usercontrol>

using system;
using system.collections.generic;
using system.componentmodel;
using system.linq;
using system.reflection;
using system.text;
using system.threading.tasks;
using system.windows;
using system.windows.controls;
using system.windows.data;
using system.windows.documents;
using system.windows.input;
using system.windows.media;
using system.windows.media.imaging;
using system.windows.navigation;
using system.windows.shapes;

namespace flowchart
{
    /// <summary>
    /// propertiesview.xaml 的交互逻辑
    /// </summary>
    public partial class propertiesview : usercontrol
    {
        public propertiesview()
        {
            initializecomponent();
            displayproperties();
        }

        private object _selectedobject;
        public object selectedobject
        {
            get { return _selectedobject; }
            set
            {
                if (_selectedobject != value)
                {
                    var obj = _selectedobject as inotifypropertychanged;
                    if (obj != null)
                        obj.propertychanged -= propertychanged;

                    _selectedobject = value;
                    displayproperties();

                    obj = _selectedobject as inotifypropertychanged;
                    if (obj != null)
                        obj.propertychanged += propertychanged;
                }
            }
        }

        void propertychanged(object sender, propertychangedeventargs e)
        {
            displayproperties();
        }

        private void displayproperties()
        {
            _panel.children.clear();
            cleargrid();
            if (selectedobject != null)
            {
                int row = 0;
                foreach (var prop in selectedobject.gettype().getproperties().orderby(p => p.name))
                {
                    var attr = prop.getcustomattributes(typeof(browsableattribute), true);
                    if (attr.length == 0 || (attr[0] as browsableattribute).browsable)
                    {
                        displayproperty(prop, row);
                        row++;
                    }
                }
                _panel.children.add(_gridcontainer);
            }
            else
            {
                _panel.children.add(_label);
            }
        }

        private void cleargrid()
        {
            _grid.rowdefinitions.clear();
            for (int i = _grid.children.count - 1; i >= 0; i--)
            {
                if (_grid.children[i] != _vline && _grid.children[i] != _splitter)
                    _grid.children.removeat(i);
            }
        }

        private void displayproperty(propertyinfo prop, int row)
        {
            var rowdef = new rowdefinition();
            rowdef.height = new gridlength(math.max(20, this.fontsize * 2));
            _grid.rowdefinitions.add(rowdef);

            var tb = new textblock() { text = prop.name };
            tb.margin = new thickness(4);
            grid.setcolumn(tb, 0);
            grid.setrow(tb, _grid.rowdefinitions.count - 1);

            var ed = new textbox();
            ed.previewkeydown += new keyeventhandler(ed_keydown);
            ed.margin = new thickness(0, 2, 14, 0);
            ed.borderthickness = new thickness(0);
            grid.setcolumn(ed, 1);
            grid.setrow(ed, _grid.rowdefinitions.count - 1);

            var line = new line();
            line.style = (style)resources["gridhorizontallinestyle"];
            grid.setrow(line, row);

            var binding = new binding(prop.name);
            binding.source = selectedobject;
            binding.validatesonexceptions = true;
            binding.mode = bindingmode.oneway;
            ed.isenabled = false;
            if (prop.canwrite)
            {
                ed.isenabled = true;
                var mi = prop.getsetmethod();
                if (mi != null && mi.ispublic)
                    binding.mode = bindingmode.twoway;
            }
            ed.setbinding(textbox.textproperty, binding);

            var template = (controltemplate)resources["validationerrortemplate"];
            validation.seterrortemplate(ed, template);

            _grid.children.add(tb);
            _grid.children.add(ed);
            _grid.children.add(line);
        }

        void ed_keydown(object sender, keyeventargs e)
        {
            var ed = sender as textbox;
            if (ed != null)
            {
                if (e.key == key.enter)
                {
                    ed.getbindingexpression(textbox.textproperty).updatesource();
                    e.handled = true;
                }
                else if (e.key == key.escape)
                    ed.getbindingexpression(textbox.textproperty).updatetarget();
            }
        }

    }
}
