MySQL高可用集群部署与运维超完整手册(推荐!)

#!/bin/bash
# ========== mysql 基础安装脚本 (all nodes) ==========
# 1. 创建用户和目录
groupadd mysql
useradd -r -g mysql -s /bin/false mysql
mkdir -p /data1/mysql/{data,logs,tmp}
chown -r mysql:mysql /data1/mysql

# 关闭selinux
sudo sed -i 's/selinux=enforcing/selinux=disabled/g' /etc/selinux/config
sudo reboot


# 2. 安装依赖（在线优先，离线备用）
echo “正在安装系统依赖...”
dnf install -y libaio numactl-libs openssl libtirpc ncurses-compat-libs 2>/dev/null || {
    echo “在线安装失败，尝试使用离线依赖包...”
    rpm -ivh ./deps/*.rpm --nodeps 2>/dev/null || true
}

# 3. 解压并安装 mysql
echo “正在安装 mysql...”
tar -xf /data1/mysql-8.0.44-linux-glibc2.28-x86_64.tar.xz
mv /data1/mysql-8.0.44-linux-glibc2.28-x86_64/* /data1/mysql/

# 4. 创建软链接
ln -sf /data1/mysql/bin/mysql /usr/local/bin/mysql
ln -sf /data1/mysql/bin/mysqld /usr/local/bin/mysqld
ln -sf /data1/mysql/bin/mysqld_safe /usr/local/bin/mysqld_safe

# 5. 创建主配置文件 /etc/my.cnf
# 注意：初始时 plugin-load 行被注释，将在动态配置后启用。
cat > /etc/my.cnf << 'eof'
[mysqld]
basedir=/data1/mysql
datadir=/data1/mysql/data
socket=/data1/mysql/mysql.sock
port=3306

character-set-server=utf8mb4
collation-server=utf8mb4_unicode_ci
#default_authentication_plugin=mysql_native_password

max_connections=1000
max_connect_errors=100000
table_open_cache=2000
thread_cache_size=100
tmp_table_size=64m
max_heap_table_size=64m

log-error=/data1/mysql/logs/mysql-error.log
slow_query_log=1
slow_query_log_file=/data1/mysql/logs/mysql-slow.log
long_query_time=2
log-bin=/data1/mysql/logs/mysql-bin
binlog_format=row
binlog_expire_logs_seconds=604800

innodb_buffer_pool_size=1g
innodb_log_file_size=256m
innodb_flush_method=o_direct
innodb_flush_log_at_trx_commit=1
innodb_file_per_table=1

server_id=1
report_host=192.168.65.137

gtid_mode=on
enforce_gtid_consistency=on
binlog_checksum=none
log_slave_updates=on
binlog_row_image=full

#初始注释，步骤3.2中启用
#plugin-load="group_replication.so"
disabled_storage_engines="myisam,blackhole,federated,archive,memory"

#ssl_ca=/etc/mysql/ca.pem
#ssl_cert=/etc/mysql/server-cert.pem
#ssl_key=/etc/mysql/server-key.pem
#require_secure_transport=on

[mysql]
default-character-set=utf8mb4
socket=/data1/mysql/mysql.sock

[client]
socket=/data1/mysql/mysql.sock
eof

# 6. 初始化 mysql (使用 --initialize-insecure)
/data1/mysql/bin/mysqld --defaults-file=/etc/my.cnf \
  --initialize-insecure --user=mysql \
  --basedir=/data1/mysql --datadir=/data1/mysql/data

# 7. 配置并启动 systemd 服务
cat > /etc/systemd/system/mysqld.service << 'eof'
[unit]
description=mysql server
after=network.target
[service]
type=simple
user=mysql
group=mysql
execstart=/usr/local/bin/mysqld --defaults-file=/etc/my.cnf
limitnofile=65535
restart=on-failure
restartsec=10
timeoutsec=300
[install]
wantedby=multi-user.target
eof

systemctl daemon-reload
systemctl start mysqld
systemctl enable mysqld

mysql -uroot << 'eof'
-- 1. 安装插件
install plugin group_replication soname 'group_replication.so';

-- 2. 设置全局变量 (请替换ip为当前节点实际ip)
set global group_replication_group_name = 'aaaaaaaa-aaaa-aaaa-aaaa-aaaaaaaaaaaa';
set global group_replication_local_address = '192.168.65.137:33061';
set global group_replication_group_seeds = '192.168.65.137:33061,192.168.65.142:33061,192.168.65.143:33061';
set global group_replication_ip_allowlist = '10.0.1.0/24,127.0.0.1/32,localhost';
set global group_replication_bootstrap_group = off;
set global group_replication_single_primary_mode = on;

-- 3. 使用 persist 使配置持久化（重启后生效）
set persist group_replication_group_name = 'aaaaaaaa-aaaa-aaaa-aaaa-aaaaaaaaaaaa';
set persist group_replication_local_address = '192.168.65.137:33061';
set persist group_replication_group_seeds = '192.168.65.137:33061,192.168.65.142:33061,192.168.65.143:33061';
set persist group_replication_ip_allowlist = '10.0.1.0/24,127.0.0.1/32,localhost';
eof

# 1. 编辑配置文件，取消 plugin-load 行的注释
sed -i 's/^#plugin-load=“group_replication.so”/plugin-load=“group_replication.so”/' /etc/my.cnf

# 2. 重启mysql服务
systemctl restart mysqld

# 1. 设置管理用户和权限（同您提供的命令）
mysql -uroot << 'eof'
alter user 'root'@'localhost' identified by 'mysql#password';
create user 'repl'@'%' identified by 'mysql#password';
grant replication slave on *.* to 'repl'@'%';
create user 'clusteradmin'@'%' identified by 'mysql#password';
grant all privileges on *.* to 'clusteradmin'@'%' with grant option;
grant group_replication_admin on *.* to 'clusteradmin'@'%';
flush privileges;
eof

#允许任何ip登录
mysql -uroot -p'mysql#password' -h127.0.0.1 -p3306 -e "create user if not exists 'root'@'%' identified by 'mysql#password';grant all privileges on *.* to 'root'@'%' with grant option;flush privileges;"

# 2. 引导并启动组复制
mysql -uroot -pmysql#password << 'eof'
set global group_replication_bootstrap_group=on;
change master to master_user='repl', master_password='mysql#password' for channel 'group_replication_recovery';
start group_replication;
set global group_replication_bootstrap_group=off;
eof

mysql -uroot -pmysql#password << 'eof'
change master to master_user='repl', master_password='mysql#password' for channel 'group_replication_recovery';
start group_replication;
eof

# 1. 开放mysql及组复制通信端口
firewall-cmd --permanent --add-port=3306/tcp
firewall-cmd --permanent --add-port=33061/tcp

# 2. （可选）在主节点开放mysql router端口
# 判断如果是主节点（例如通过ip判断），则开放router端口
if [[ “$(hostname -i)“ =~ 192.168.65.137 ]]; then
    firewall-cmd --permanent --add-port=6446/tcp
    firewall-cmd --permanent --add-port=6447/tcp
fi

# 3. 重新加载配置
firewall-cmd --reload
# 4. 验证结果
firewall-cmd --list-ports

#!/bin/bash
# ========== mysql router 部署脚本 ==========
# 1. 创建系统用户
groupadd mysqlrouter
useradd -r -g mysqlrouter -s /bin/false mysqlrouter

# 2. 解压软件
tar -xf mysql-router-8.0.37-linux-glibc2.17-x86_64.tar.gz -c /tmp
mv /tmp/mysql-router-8.0.37-linux-glibc2.17-x86_64 /data1/mysql-router

# 3. 创建软链接
ln -sf /data1/mysql-router/bin/mysqlrouter /usr/bin/mysqlrouter

# 4. 创建目录与配置文件
mkdir -p /etc/mysqlrouter
#引导生成配置文件
mysqlrouter --user=mysqlrouter --bootstrap root@192.168.65.137:3306 --directory /etc/mysqlrouter

# 5. 设置权限
chown -r mysqlrouter:mysqlrouter /etc/mysqlrouter /data1/mysql-router

# 6. 创建并启动系统服务
cat > /etc/systemd/system/mysqlrouter.service << 'eof'
[unit]
description=mysql router
after=network.target mysqld.service
wants=network.target mysqld.service
documentation=man:mysqlrouter

[service]
type=forking
execstart=/etc/mysqlrouter/start.sh
workingdirectory=/etc/mysqlrouter
user=mysqlrouter
group=mysqlrouter
pidfile=/etc/mysqlrouter/mysqlrouter.pid
environment="path=/usr/local/sbin:/usr/local/bin:/usr/sbin:/usr/bin:/sbin:/bin"
environment="router_pid=/etc/mysqlrouter/mysqlrouter.pid"

restart=on-failure
restartsec=5
startlimitinterval=100
startlimitburst=10
timeoutstartsec=300
timeoutstopsec=30
killsignal=sigterm
killmode=mixed

[install]
wantedby=multi-user.target
eof

systemctl daemon-reload && systemctl start mysqlrouter && systemctl status mysqlrouter

echo “mysql router 部署完成！”

# 1. 解压安装包
tar -xf mysql-shell-8.0.37-linux-glibc2.17-x86_64.tar.gz
mv mysql-shell-8.0.37-linux-glibc2.17-x86_64 /data1/mysql-shell

# 2. 创建软链接
ln -sf /data1/mysql-shell/bin/mysqlsh /usr/local/bin/mysqlsh
ln -sf /data1/mysql-shell/bin/mysqlsh /usr/bin/mysqlsh

# 3. 验证安装
mysqlsh --version

cat > /tmp/mysql_script.js << 'eof'
try {
    print("连接到主节点...");
    shell.connect('clusteradmin:mysql%23password@192.168.65.137:3306');

    print("接管现有的 group replication 为 innodb cluster...");
    var cluster = dba.createcluster('mycluster', {adoptfromgr: true});

    print("集群接管完成！");
    print("集群状态：");
    cluster.status();

} catch(e) {
    print("错误: " + e.message);
    print("详细信息: " + json.stringify(e));
}
eof


mysqlsh --js -f /tmp/mysql_script.js

cat > /tmp/check_node.js << 'eof'
// 定义集群节点
var instances = [
    {host: '192.168.65.137', port: 3306, label: '节点1'},
    {host: '192.168.65.142', port: 3306, label: '节点2'},
    {host: '192.168.65.143', port: 3306, label: '节点3'}
];

var username = 'clusteradmin';
var password = 'mysql#password';

// 配置实例
print("\n配置实例...");

for (var i = 0; i < instances.length; i++) {
	var instance = instances[i];
	print("\n配置节点 " + instance.label + " (" + instance.host + ":" + instance.port + ")...");

	var primarysession = shell.connect({
		host: instance.host,
		port: instance.port,
		user: username,
		password: password
	});

	if (!primarysession) {
		throw new error("无法连接到节点");
	}
	print("✓ 成功连接到节点");

	print("\n2. 检查节点配置...");
	var checkresult = dba.checkinstanceconfiguration({
		host: instance.host,
		port: instance.port,
		user: username,
		password: password
	});

	print("配置检查结果状态: " + checkresult.status);

	if (checkresult.status === 'ok') {
		print("\n✓ 节点配置正常");
	} else if (checkresult.status === 'error') {
		print("\n✗ 节点配置有错误，需要修复");
		print("\n错误信息: " + checkresult.errors);
		print("\n正在自动配置节点...");
		var configureresult = dba.configureinstance({
			host: instance.host,
			port: instance.port,
			user: username,
			password: password
		}, {restart: true});

		print("\n配置结果: " + json.stringify(configureresult, null, 2));

		if (configureresult.status === 'ok') {
			print("\n✓ 节点配置成功");
			// 重新连接
			primarysession = shell.connect({
				host: instance.host,
				port: instance.port,
				user: username,
				password: password
			});
		} else {
			throw new error("节点配置失败: " + configureresult.errors);
		}
	}
}
eof

mysqlsh --js -f /tmp/check_node.js


cat > /tmp/create_cluster.js << 'eof'
// 定义集群节点
var instances = [
    {host: '192.168.65.137', port: 3306, label: '节点1'},
    {host: '192.168.65.142', port: 3306, label: '节点2'},
    {host: '192.168.65.143', port: 3306, label: '节点3'}
];

var username = 'clusteradmin';
var password = 'mysql#password';

print("\n创建集群...");

var clustername = 'mycluster';
print("\n正在创建集群: " + clustername);

try {
	print("连接到主节点: " + instances[0].label);
    var primarysession = shell.connect({
        host: instances[0].host,
        port: instances[0].port,
        user: username,
        password: password,
        scheme: 'mysql'
    });

    if (!primarysession) {
        throw new error("无法连接到主节点");
    }

    var cluster = dba.createcluster(clustername);

    if (cluster) {
        print("✓ 集群创建成功");
        print("\n集群名称: " + clustername);
        print("\n主节点: " + instances[0].host + ":" + instances[0].port);

        // 检查集群状态
        print("\n集群初始状态:");
        var clusterstatus = cluster.status({extended: 0});
        print(json.stringify(clusterstatus, null, 2));

    } else {
        throw new error("集群创建失败");
    }

    print("\n添加其他实例到集群...");

    for (var i = 1; i < instances.length; i++) {
        var instance = instances[i];
        print("\n添加 " + instance.label + " (" + instance.host + ":" + instance.port + ") 到集群...");

        try {
            // 尝试添加实例
            var addresult = cluster.addinstance({
					host: instance.host,
					port: instance.port,
					user: username,
					password: password
				}, {
					recoverymethod: 'clone'
				});

            print("\n  ✓ " + instance.label + " 添加成功");
            print("\n  恢复方法: clone");
        } catch (adderr) {
            print("\n  ✗ 添加 " + instance.label + " 失败: " + adderr.message);
        }
    }

    print("\n集群最终状态:");

    var finalstatus = cluster.status({extended: 1});

    print("\n集群成员:");
    print(json.stringify(finalstatus, null, 2));

    print("\n设置集群选项...");

    try {
        cluster.setoption("exitstateaction", "offline_mode");
	cluster.setoption("memberweight", 50);
        cluster.setoption("consistency", "before_on_primary_failover");
        cluster.setoption("ipallowlist", "192.168.65.0/24,127.0.0.1");
        cluster.setoption("failoverconsistency", "eventual");

        print("✓ 集群选项设置完成");
    } catch (optionerr) {
        print("⚠ 设置集群选项时出错: " + optionerr.message);
    }
} catch (e) {
    print("\n✗ 错误发生: " + e.message);
    print("错误堆栈: " + e.stack);

    // 尝试获取更多错误信息
    if (e.code) {
        print("错误代码: " + e.code);
    }

    // 检查集群是否存在
    try {
        var existingcluster = dba.getcluster(clustername);
        if (existingcluster) {
            print("\n⚠ 集群已存在，当前状态:");
            print(json.stringify(existingcluster.status({extended: 0}), null, 2));
        }
    } catch (clustererr) {
        // 忽略
    }
}
eof

mysqlsh --js -f /tmp/create_cluster.js


cat > /tmp/check_cluster.js << 'eof'
// 定义集群节点
var instances = [
    {host: '192.168.65.137', port: 3306, label: '节点1'},
    {host: '192.168.65.142', port: 3306, label: '节点2'},
    {host: '192.168.65.143', port: 3306, label: '节点3'}
];

var username = 'clusteradmin';
var password = 'mysql#password';

var clustername = 'mycluster';

try {
    print("验证集群...\n");

    var clustervalid = dba.getcluster(clustername);
    if (clustervalid) {
        print("✓ 集群验证成功\n");
        print("集群对象有效，可以使用以下命令管理:\n");
        print("  var cluster = dba.getcluster('" + clustername + "');\n");
        print("  cluster.status();\n");
        print("  cluster.describe();\n");
    }

    print("\n=== mysql innodb cluster 创建完成 ===");
    print("\n管理命令:");
    print("1. 查看集群状态: cluster.status()\n");
    print("2. 查看集群描述: cluster.describe()\n");
    print("3. 切换主节点: cluster.setprimaryinstance('host:port')\n");
    print("4. 重新扫描集群: cluster.rescan()\n");
    print("5. 移除实例: cluster.removeinstance('host:port')\n");
} catch (e) {
    print("\n✗ 错误发生: " + e.message);
    print("错误堆栈: " + e.stack);

    // 尝试获取更多错误信息
    if (e.code) {
        print("错误代码: " + e.code);
    }

    // 检查集群是否存在
    try {
        var existingcluster = dba.getcluster(clustername);
        if (existingcluster) {
            print("\n⚠ 集群已存在，当前状态:");
            print(json.stringify(existingcluster.status({extended: 0}), null, 2));
        }
    } catch (clustererr) {
        // 忽略
    }
}
eof


mysqlsh --js -f /tmp/check_cluster.js

# 1. 检查集群状态
mysql -uclusteradmin -p'mysql#password' -h192.168.65.137 -e “
select member_host, member_port, member_state, member_role
from performance_schema.replication_group_members\g”

# 2. 测试router连接
mysql -uclusteradmin -p'mysql#password' -h192.168.65.137 -p6446 -e “select @@hostname;”
mysql -uclusteradmin -p'mysql#password' -h192.168.65.137 -p6447 -e “select @@hostname;”

# 3.1 测试同步，主节点执行
mysql -uclusteradmin -pmysql#password -h192.168.65.137 << eof
create database if not exists cluster_test;
use cluster_test;
create table if not exists test_sync (
    id int auto_increment primary key,
    node_name varchar(50),
    created_at timestamp default current_timestamp
);
insert into test_sync (node_name) values ('from_node1');
select * from test_sync;
eof

# 3.2 每个从节点看是否有数据
mysql -uclusteradmin -pmysql#password -h192.168.65.142 -e "select * from cluster_test.test_sync;"
mysql -uclusteradmin -pmysql#password -h192.168.65.143 -e "select * from cluster_test.test_sync;"

# 查看集群成员状态
mysql -uroot -p'mysql#password' -e “select * from performance_schema.replication_group_members;”
# 查看复制延迟
mysql -uroot -p'mysql#password' -e “select * from performance_schema.replication_group_member_stats\g”
# 检查错误日志
tail -50 /data1/mysql/logs/mysql-error.log

# 模拟主节点故障
# 1. 停止主节点的mysql服务
systemctl stop mysqld

# 2. 观察集群自动选举新主节点
mysql -uroot -pmysql#password -h192.168.65.142 -e "select * from performance_schema.replication_group_members;"

# 3. 通过router测试连接
mysql -uroot -pmysql#password -h192.168.65.137 -p6446 -e "select @@hostname;"

# 4. 恢复原主节点
systemctl start mysqld

error while loading shared libraries:
1. libaio.so.1: cannot open shared object file
2. libnuma.so.1: cannot open shared object file

# openeuler 23.03 系统
sudo dnf install libaio libaio-devel numactl numactl-devel openssl openssl-devel

# 安装后运行
sudo ldconfig

# 验证依赖库
ldd /data1/mysql/bin/mysqld | grep -e "libaio|libnuma"

process: 30526 execstart=/usr/local/mysql/bin/mysqld --defaults-file=/etc/my.cnf
(code=exited, status=203/exec)

# 1. 检查 mysqld 路径是否正确
ls -la /data1/mysql/bin/mysqld

# 2. 修正 systemd 服务文件（已在上面配置中修正）
# 3. 设置正确权限
sudo chmod 755 /data1/mysql/bin/mysqld

# 4. 重新加载 systemd
sudo systemctl daemon-reload
sudo systemctl restart mysql

channel_name    member_id       member_host     member_port     member_state    member_role
group_replication_applier       113b5a00-d7fa-11f0-b01c-fa163e5fc9a1    192.168.65.137       3306    online  primary
group_replication_applier       11476a61-d7fa-11f0-8f8b-fa163ed8b49b    192.168.65.142      3306    recovering      secondary
group_replication_applier       115ee1ec-d7fa-11f0-9029-fa163e2d65c6    192.168.65.143      3306    recovering      secondary

# 1. 查看恢复进度
mysql -h192.168.65.142 -uroot -pmysql#password -e "
select
    channel_name,
    service_state,
    remaining_delay,
    count_transactions_retries
from performance_schema.replication_connection_status
where channel_name = 'group_replication_applier';
"

# 2. 查看恢复错误（如果有）
mysql -h192.168.65.142 -uroot -pmysql#password -e "
select
    channel_name,
    last_error_number,
    last_error_message,
    last_error_timestamp
from performance_schema.replication_applier_status_by_worker
where last_error_number != 0;
"

# 3. 查看恢复线程状态
mysql -h192.168.65.142 -uroot -pmysql#password -e "show processlist;" | grep -i recover

# 4. 如果长时间处于 recovering（超过30分钟），尝试：
mysql -h192.168.65.142 -uroot -pmysql#password << 'eof'
stop group_replication;
start group_replication;
eof

[error] [my-011526] [repl] plugin group_replication reported:
'this member has more executed transactions than those present in the group.
local transactions: 11476a61-d7fa-11f0-8f8b-fa163ed8b49b:1-11 >
group transactions: 113b5a00-d7fa-11f0-b01c-fa163e5fc9a1:1-11, aaaaaaaa-aaaa-aaaa-aaaa-aaaaaaaaaaaa:1'
[error] [my-011522] [repl] plugin group_replication reported:
'the member contains transactions not present in the group. the member will now exit the group.'

mysql -uroot -pmysql#password << 'eof'
-- 1. 停止组复制
stop group_replication;

-- 2. 临时禁用只读模式
set global read_only = off;
set global super_read_only = off;

-- 3. 跳过问题事务
set gtid_next='113b5a00-d7fa-11f0-b01c-fa163e5fc9a1:7';
begin;
commit;
set gtid_next='automatic';

-- 4. 重新启动组复制（会自动设置回只读模式）
start group_replication;

-- 5. 检查状态
select * from performance_schema.replication_group_members;
eof

[warning] [my-011735] [repl] plugin group_replication reported:
'[gcs] connection attempt from ip address ::ffff:192.168.65.142 refused.
address is not in the ip allowlist.'
[error] [my-011735] [repl] plugin group_replication reported:
'[gcs] error on opening a connection to peer node 192.168.65.143:33061 when joining a group.
my local port is: 33061.'

# 在所有节点上执行（需要持久化配置）
mysql -uroot -pmysql#password << 'eof'
-- 查看当前的ip白名单
show variables like 'group_replication_ip_allowlist';

-- 持久化添加ip地址到白名单（使用 set persist）
set persist group_replication_ip_allowlist = '10.0.1.0/24,127.0.0.1/32,localhost';

-- 或者允许所有ip（仅测试环境）
-- set persist group_replication_ip_allowlist = '0.0.0.0/0';

-- 验证持久化设置
select * from performance_schema.persisted_variables
where variable_name = 'group_replication_ip_allowlist';

-- 重启组复制使设置生效
stop group_replication;
start group_replication;
eof

# 验证配置是否已持久化
mysql -uroot -pmysql#password -e "show variables like 'group_replication_ip_allowlist';"

[error] [my-011735] [repl] plugin group_replication reported:
'[gcs] there is no local ip address matching the one configured for the local node (192.168.65.137:33061).'

# 1. 查看服务器ip地址
ip addr show
hostname -i

# 2. 修改group replication本地地址配置（使用持久化设置）
mysql -uroot -pmysql#password << 'eof'
-- 查看当前配置
show variables like 'group_replication_local_address';

-- 持久化修改为正确的ip地址（使用实际ip）
set persist group_replication_local_address = '192.168.65.137:33061';

-- 检查持久化变量
select * from performance_schema.persisted_variables
where variable_name like 'group_replication%';
eof

# 3. 重启mysql服务使持久化配置生效
sudo systemctl restart mysqld

# 4. 重启组复制
mysql -uroot -pmysql#password << 'eof'
stop group_replication;
start group_replication;
eof

# 1. 检查插件是否正确加载
mysql -uroot -pmysql#password -e "show plugins;" | grep group_replication

# 2. 检查group replication是否已启动
mysql -uroot -pmysql#password -e "show status like 'group_replication%';"

# 3. 如果没有启动，配置并启动（使用持久化设置）
mysql -uroot -pmysql#password << 'eof'
-- 持久化配置group replication参数
set persist group_replication_group_name = 'aaaaaaaa-aaaa-aaaa-aaaa-aaaaaaaaaaaa';
set persist group_replication_local_address = '192.168.65.137:33061';
set persist group_replication_group_seeds = '192.168.65.137:33061,192.168.65.142:33061,192.168.65.143:33061';
set persist group_replication_single_primary_mode = on;
set persist group_replication_enforce_update_everywhere_checks = off;

-- 临时设置引导模式
set global group_replication_bootstrap_group = on;

-- 启动group replication（这会创建监听端口）
start group_replication;

-- 关闭引导模式
set global group_replication_bootstrap_group = off;
eof

# 4. 验证端口监听
netstat -tlnp | grep 33061
ss -tlnp | grep 33061

# 5. 检查防火墙（openeuler）
sudo firewall-cmd --list-ports
sudo firewall-cmd --add-port=33061/tcp --permanent
sudo firewall-cmd --reload

the start group_replication command failed as there was an error when initializing the group communication layer

# 1. 检查关键配置
mysql -uroot -pmysql#password << 'eof'
-- 检查group replication配置
select
    variable_name,
    variable_value
from performance_schema.global_variables
where variable_name like 'group_replication%'
order by variable_name;

-- 检查插件状态
select plugin_name, plugin_status
from information_schema.plugins
where plugin_name like '%group_replication%';
eof

# 2. 清理并重新配置（使用持久化设置）
mysql -uroot -pmysql#password << 'eof'
-- 停止组复制
stop group_replication;

-- 重置主节点
reset master;

-- 持久化重新配置
set persist group_replication_group_name = uuid();
set persist group_replication_local_address = '192.168.65.137:33061';
set persist group_replication_group_seeds = '192.168.65.137:33061,192.168.65.142:33061,192.168.65.143:33061';
set persist group_replication_ip_allowlist = '10.0.1.0/24,127.0.0.1/32';

-- 临时设置引导模式
set global group_replication_bootstrap_group = on;

-- 重新启动
start group_replication;
set global group_replication_bootstrap_group = off;
eof

# 3. 重启mysql服务
sudo systemctl restart mysqld

[error] [my-000067] [server] unknown variable 'group_replication_group_name=aaaaaaaa-aaaa-aaaa-aaaa-aaaaaaaaaaaa'.
[error] [my-013236] [server] the designated data directory /data1/mysql/data/ is unusable.

# 1. 正确的初始化命令（不要在初始化时包含运行时参数）
sudo -u mysql /data1/mysql/bin/mysqld --initialize \
  --user=mysql \
  --datadir=/data1/mysql/data \
  --basedir=/data1/mysql

# 2. 启动mysql后，在配置文件中添加group replication配置
cat >> /etc/my.cnf << 'eof'
# group replication 配置
plugin-load-add=group_replication.so
group_replication=force_plus_permanent
group_replication_start_on_boot=off
# 注意：这里只是设置默认值，实际使用set persist
# group_replication_group_name="aaaaaaaa-aaaa-aaaa-aaaa-aaaaaaaaaaaa"
# group_replication_local_address="192.168.65.137:33061"
# group_replication_group_seeds="192.168.65.137:33061,192.168.65.142:33061,192.168.65.143:33061"
eof

# 3. 启动mysql
sudo systemctl restart mysql

# 4. 使用set persist动态配置group replication参数
mysql -uroot -pmysql#password << 'eof'
-- 安装插件（如果未自动加载）
install plugin group_replication soname 'group_replication.so';

-- 使用set persist持久化配置
set persist group_replication_group_name = 'aaaaaaaa-aaaa-aaaa-aaaa-aaaaaaaaaaaa';
set persist group_replication_local_address = '192.168.65.137:33061';
set persist group_replication_group_seeds = '192.168.65.137:33061,192.168.65.142:33061,192.168.65.143:33061';
eof

mysqld: table 'mysql.plugin' doesn't exist

# 1. 重新初始化mysql数据目录（注意：会丢失所有数据！）
sudo systemctl stop mysql
sudo rm -rf /data1/mysql/data/*
sudo -u mysql /data1/mysql/bin/mysqld --initialize \
  --user=mysql \
  --datadir=/data1/mysql/data \
  --basedir=/data1/mysql

# 2. 获取初始密码
sudo grep 'temporary password' /data1/mysql/data/error.log

# 3. 启动mysql并修改密码
sudo systemctl start mysql
# 用临时密码登录并修改
mysql -uroot -p临时密码 -e "alter user 'root'@'localhost' identified by 'mysql#password';"

# 4. 持久化安装和配置group replication插件
mysql -uroot -pmysql#password << 'eof'
-- 安装插件
install plugin group_replication soname 'group_replication.so';

-- 验证插件
select plugin_name, plugin_status
from information_schema.plugins
where plugin_name = 'group_replication';

-- 持久化配置参数
set persist group_replication_group_name = 'aaaaaaaa-aaaa-aaaa-aaaa-aaaaaaaaaaaa';
set persist group_replication_local_address = '192.168.65.137:33061';
set persist group_replication_group_seeds = '192.168.65.137:33061,192.168.65.142:33061,192.168.65.143:33061';
set persist group_replication_bootstrap_group = off;
eof

# 5. 验证33061端口
sleep 5
netstat -tlnp | grep 33061

function 'group_replication' already exists

# 1. 检查插件是否已安装
mysql -uroot -pmysql#password -e "show plugins;" | grep group_replication

# 2. 如果已安装，直接使用已安装的插件继续配置
mysql -uroot -pmysql#password << 'eof'
-- 跳过安装，直接配置
set persist group_replication_group_name = uuid();
set persist group_replication_local_address = '192.168.65.137:33061';
set persist group_replication_group_seeds = '192.168.65.137:33061,192.168.65.142:33061,192.168.65.143:33061';
set persist group_replication_ip_allowlist = '10.0.1.0/24,127.0.0.1/32';

-- 临时设置引导模式
set global group_replication_bootstrap_group = on;

-- 启动组复制
start group_replication;

-- 关闭引导模式
set global group_replication_bootstrap_group = off;
eof

# 3. 如果需要重新安装（不推荐，除非插件损坏）
mysql -uroot -pmysql#password << 'eof'
-- 卸载插件
uninstall plugin group_replication;

-- 等待几秒
do sleep(2);

-- 重新安装
install plugin group_replication soname 'group_replication.so';
eof

# 关键：使用 metadata_cache（下划线），不是 metadata-cache
[metadata_cache:mycluster]
router_id=1
# 关键：添加 mysql:// 协议前缀
bootstrap_server_addresses=mysql://192.168.65.137:3306
user=root
password="mysql#password"
ttl=5

[routing:rw]
bind_address=0.0.0.0
bind_port=6446
destinations=metadata-cache://mycluster/default?role=primary
routing_strategy=round-robin
protocol=classic

[routing:ro]
bind_address=0.0.0.0
bind_port=6447
destinations=metadata-cache://mycluster/default?role=secondary
routing_strategy=round-robin
protocol=classic

error: can't open file '/data1/mysql-router/mysqlrouter.key': no such file or directory

# 1. 创建目录
sudo mkdir -p /data1/mysql-router/mysqlrouter
sudo chown -r mysqlrouter:mysqlrouter /data1/mysql-router

# 2. 创建 master key 文件
sudo -u mysqlrouter openssl rand -hex 32 > /data1/mysql-router/mysqlrouter/mysqlrouter.key
sudo chmod 600 /data1/mysql-router/mysqlrouter/mysqlrouter.key

# 3. 创建 keyring 文件
sudo -u mysqlrouter touch /data1/mysql-router/mysqlrouter/keyring
sudo chmod 600 /data1/mysql-router/mysqlrouter/keyring

# 4. 初始化 keyring（如果工具可用）
if command -v mysqlrouter_keyring > /dev/null; then
    sudo -u mysqlrouter mysqlrouter_keyring init \
        --master-key-file=/data1/mysql-router/mysqlrouter/mysqlrouter.key \
        /data1/mysql-router/mysqlrouter/keyring
fi

# 1. 检查库依赖
ldd /data1/mysql/bin/mysqld
# 2. 检查 systemd 日志
sudo journalctl -u mysql -n 100 --no-pager
# 3. 检查 mysql 错误日志
sudo tail -f /data1/mysql/data/error.log
# 4. 检查集群状态
mysql -h192.168.65.137 -uroot -pmysql#password -e "select * from performance_schema.replication_group_members;"
# 5. 检查 router 状态
sudo systemctl status mysqlrouter
# 6. 检查持久化配置
mysql -uroot -pmysql#password -e "select * from performance_schema.persisted_variables;"

应用程序
    ↓
mysql router (负载均衡/故障转移)
    ├── 读写端口: 6446 → 主节点
    └── 只读端口: 6447 → 从节点
        ↓
group replication 集群 (3节点)
    ├── 主节点: 192.168.65.137
    ├── 从节点: 192.168.65.142
    └── 从节点: 192.168.65.143

# 启动 primary 节点
mysql -h192.168.65.137 -p3306 -uclusteradmin -pmysql#password 2>/dev/null << 'sql'
stop group_replication;
reset master;
set global group_replication_bootstrap_group=on;
start group_replication;
set global group_replication_bootstrap_group=off;
select member_host, member_port, member_state, member_role from performance_schema.replication_group_members;
sql

# 去primary节点查询集群信息
mysql -h192.168.65.137 -p3306 -uclusteradmin -pmysql#password 2>/dev/null << 'sql'
show variables like 'group_replication_group_name';
show variables like 'group_replication_local_address';
show variables like 'group_replication_group_seeds';
show variables like 'group_replication_bootstrap_group';

# 节点信息
select member_host, member_port, member_state, member_role from performance_schema.replication_group_members;
sql

# 修正节点参数问题
mysql -h192.168.65.137 -p3306 -uclusteradmin -pmysql#password 2>/dev/null << 'sql'
stop group_replication;
set global group_replication_bootstrap_group=off;
set global group_replication_group_seeds='192.168.65.137:3306,192.168.65.142:3306,192.168.65.143:3306';
set global group_replication_local_address='192.168.65.137:3306';
start group_replication;
sql


# 启动 secondary 节点，需要用到集群信息
mysql -h192.168.65.142 -p3306 -uclusteradmin -pmysql#password 2>/dev/null << 'sql'
stop group_replication;

reset slave all;
reset master;

set global group_replication_bootstrap_group=off;
set global group_replication_group_name='672ba05f-e7f9-11f0-8d2e-000c29e0b548';
set global group_replication_group_seeds='192.168.65.137:3306,192.168.65.142:3306,192.168.65.143:3306';
set global group_replication_local_address='192.168.65.142:3306';

change master to master_user='clusteradmin', master_password='mysql#password' for channel 'group_replication_recovery';

start group_replication;
select member_host, member_port, member_state, member_role from performance_schema.replication_group_members;
sql


# 启动 secondary 节点，需要用到集群信息
mysql -h192.168.65.143 -p3306 -uclusteradmin -pmysql#password 2>/dev/null << 'sql'
stop group_replication;

reset slave all;
reset master;

set global group_replication_bootstrap_group=off;
set global group_replication_group_name='672ba05f-e7f9-11f0-8d2e-000c29e0b548';
set global group_replication_group_seeds='192.168.65.137:3306,192.168.65.142:3306,192.168.65.143:3306';
set global group_replication_local_address='192.168.65.143:3306';

change master to master_user='clusteradmin', master_password='mysql#password' for channel 'group_replication_recovery';

start group_replication;
select member_host, member_port, member_state, member_role from performance_schema.replication_group_members;
sql

# 下载 mysql 8.0 server
# 下载 mysql shell
# 下载 mysql router
# 下载依赖
dnf reinstall --downloadonly --downloaddir=./deps \
  libaio numactl-libs openssl libtirpc ncurses-compat-libs \
  libstdc++ libgcc pcre2 libedit numactl


# 1. 创建用户和目录
groupadd mysql
useradd -r -g mysql -s /bin/false mysql
mkdir -p /data1/mysql
mkdir -p /data1/mysql/{data,logs,tmp}
chown -r mysql:mysql /data1/mysql

# 2. 检查并安装依赖
dnf install -y libaio numactl-libs openssl libtirpc ncurses-compat-libs 2>/dev/null || {
    echo "使用离线依赖包..."
    rpm -ivh ./deps/*.rpm --nodeps 2>/dev/null || true
}

# 3. 解压并安装 mysql
tar -xf /data1/mysql-8.0.44-linux-glibc2.28-x86_64.tar.xz
mv /data1/mysql-8.0.44-linux-glibc2.28-x86_64/* /data1/mysql/

# 4. 创建软链接
ln -sf /data1/mysql/bin/mysql /usr/local/bin/mysql
ln -sf /data1/mysql/bin/mysqld /usr/local/bin/mysqld
ln -sf /data1/mysql/bin/mysqld_safe /usr/local/bin/mysqld_safe

# 5. 创建配置文件
cat > /etc/my.cnf << eof
[mysqld]
basedir=/data1/mysql
datadir=/data1/mysql/data
socket=/data1/mysql/mysql.sock
port=3306

character-set-server=utf8mb4
collation-server=utf8mb4_unicode_ci
default_authentication_plugin=mysql_native_password

max_connections=1000
max_connect_errors=100000
table_open_cache=2000
thread_cache_size=100
tmp_table_size=64m
max_heap_table_size=64m

log-error=/data1/mysql/logs/mysql-error.log
slow_query_log=1
slow_query_log_file=/data1/mysql/logs/mysql-slow.log
long_query_time=2
log-bin=/data1/mysql/logs/mysql-bin
binlog_format=row
binlog_expire_logs_seconds=604800

innodb_buffer_pool_size=1g
innodb_log_file_size=256m
innodb_flush_method=o_direct
innodb_flush_log_at_trx_commit=1
innodb_file_per_table=1

server_id=1
report_host=192.168.100.19

gtid_mode=on
enforce_gtid_consistency=on
master_info_repository=table
relay_log_info_repository=table
binlog_checksum=none
log_slave_updates=on
binlog_row_image=full

# plugin-load="group_replication.so"

transaction_write_set_extraction=xxhash64
disabled_storage_engines="myisam,blackhole,federated,archive,memory"

# ssl_ca=/etc/mysql/ca.pem
# ssl_cert=/etc/mysql/server-cert.pem
# ssl_key=/etc/mysql/server-key.pem
# require_secure_transport=on

[mysql]
default-character-set=utf8mb4
socket=/data1/mysql/mysql.sock

[client]
socket=/data1/mysql/mysql.sock
eof

# 6. 初始化 mysql
/data1/mysql/bin/mysqld --defaults-file=/etc/my.cnf \
  --initialize-insecure --user=mysql \
  --basedir=/data1/mysql --datadir=/data1/mysql/data

# 7. 创建 systemd 服务
cat > /etc/systemd/system/mysqld.service << 'eof'
[unit]
description=mysql server
after=network.target

[service]
type=simple
user=mysql
group=mysql
execstart=/usr/local/bin/mysqld --defaults-file=/etc/my.cnf
limitnofile=65535
restart=on-failure
restartsec=10
timeoutsec=300

[install]
wantedby=multi-user.target
eof

# 8. 启动全部 mysql
systemctl daemon-reload && systemctl start mysqld && systemctl enable mysqld && systemctl status mysqld

# 启动插件，每个节点的ip不一样
mysql -uroot << eof
install plugin group_replication soname 'group_replication.so';

set global gtid_mode = 'on';
set global enforce_gtid_consistency = 'on';
set global master_info_repository = 'table';
set global relay_log_info_repository = 'table';
set global binlog_checksum = 'none';
set global binlog_format = 'row';

set global transaction_write_set_extraction = 'xxhash64';
set global group_replication_group_name = 'aaaaaaaa-aaaa-aaaa-aaaa-aaaaaaaaaaaa';
set global group_replication_start_on_boot = 'off';
set global group_replication_local_address = '192.168.100.19:33061';
set global group_replication_ip_allowlist = '192.168.100.19,192.168.100.153,192.168.100.154,192.168.65.137,192.168.65.142,192.168.65.143,127.0.0.1,localhost';
set global group_replication_group_seeds = '192.168.100.19:33061,192.168.100.153:33061,192.168.100.154:33061';
set global group_replication_bootstrap_group = 'off';
set global group_replication_single_primary_mode = 'on';
set global group_replication_enforce_update_everywhere_checks = 'off';

set persist gtid_mode = 'on';
set persist enforce_gtid_consistency = 'on';
set persist master_info_repository = 'table';
set persist relay_log_info_repository = 'table';
set persist binlog_checksum = 'none';
set persist binlog_format = 'row';

set persist transaction_write_set_extraction = 'xxhash64';
set persist group_replication_group_name = 'aaaaaaaa-aaaa-aaaa-aaaa-aaaaaaaaaaaa';
set persist group_replication_start_on_boot = 'off';
set persist group_replication_local_address = '192.168.100.19:33061';
set persist group_replication_ip_allowlist = '192.168.100.19,192.168.100.153,192.168.100.154,192.168.65.137,192.168.65.142,192.168.65.143,127.0.0.1,localhost';
set persist group_replication_group_seeds = '192.168.65.137:33061,192.168.65.142:33061,192.168.65.143:33061';
set persist group_replication_bootstrap_group = 'off';
set persist group_replication_single_primary_mode = 'on';
set persist group_replication_enforce_update_everywhere_checks = 'off';
eof

设置完后，在my.cnf 开启 plugin-load="group_replication.so"，最后重启服务

# 确认修改
mysql -uroot << eof
-- 检查插件状态
show plugins;

-- 检查 group replication 变量
show variables like 'group_replication%';

-- 检查端口监听
show variables like 'port';
show variables like 'group_replication_local_address';
"


# 主节点上执行
# 9. 设置 root 密码
mysql -uroot << eof
alter user 'root'@'localhost' identified by 'mysql#password';

create user 'root'@'%' identified by 'mysql#password';
grant all privileges on *.* to 'root'@'%' with grant option;

create user 'repl'@'%' identified by 'mysql#password';
grant replication slave on *.* to 'repl'@'%';
grant backup_admin on *.* to 'repl'@'%';

create user 'clusteradmin'@'%' identified by 'mysql#password';
grant all privileges on *.* to 'clusteradmin'@'%' with grant option;
grant clone_admin, system_variables_admin on *.* to 'clusteradmin'@'%';
grant group_replication_admin on *.* to 'clusteradmin'@'%';

flush privileges;
eof

# 3. 配置group replication
mysql -uroot -pmysql#password << eof
-- 设置恢复通道
set global group_replication_bootstrap_group=on;
change master to master_user='repl', master_password='mysql#password'
for channel 'group_replication_recovery';

-- 启动组复制
start group_replication;

-- 关闭引导模式
set global group_replication_bootstrap_group=off;
eof

# 4. 验证主节点状态
mysql -uroot -pmysql#password << eof
select * from performance_schema.replication_group_members;
eof

# 其他节点
# 2. 加入集群
mysql -uroot -pmysql#password << eof
-- 设置恢复通道
change master to master_user='repl', master_password='mysql#password'
for channel 'group_replication_recovery';

-- 启动组复制
start group_replication;
eof

# 3. 验证状态
mysql -uroot -pmysql#password << eof
select * from performance_schema.replication_group_members;
eof


group replication（gr） 集群创建到这就行
