简介
本文介绍了一个基于web的sql执行工具的设计与实现,该工具允许用户通过浏览器直接执行sql语句并查看结果。系统采用前后端分离架构,后端基于spring boot框架实现sql执行引擎,前端使用vue.js构建用户界面。该系统提供了直观的sql编辑器、数据库表管理、历史查询记录和结果展示等功能,有效提高了数据库操作效率。
(本质就是客户端不知为何连接不上服务器的数据库,紧急情况下,手搓了一个sql 执行器)
本文介绍的网页版sql执行工具,通过整合spring boot后端与vue前端,实现了数据库管理的范式转移,将复杂操作转化为直观的web界面体验。
技术架构解析
后端核心设计:
import org.slf4j.logger; import org.slf4j.loggerfactory; import org.springframework.beans.factory.annotation.autowired; import org.springframework.jdbc.core.connectioncallback; import org.springframework.jdbc.core.jdbctemplate; import org.springframework.jdbc.core.resultsetextractor; import org.springframework.web.bind.annotation.*; import java.sql.databasemetadata; import java.sql.resultset; import java.sql.resultsetmetadata; import java.util.*; /** * @author:derek_smart * @date:2025/8/4 17:17 */ @restcontroller @requestmapping("/sqlutil") public class sqlutilresource { @autowired private jdbctemplate jdbctemplate; private final logger logger = loggerfactory.getlogger(sqlutilresource.class); @postmapping("/executesqlp") public map<string, object> executesqlp(@requestbody sqlrequest request) { try { string sql = request.getsql(); list<object> params = request.getparams(); if (sql.trim().touppercase().startswith("select")) { // 查询操作 list<map<string, object>> result = jdbctemplate.query(sql, params.toarray(), (rs, rownum) -> { map<string, object> row = new linkedhashmap<>(); resultsetmetadata metadata = rs.getmetadata(); int columncount = metadata.getcolumncount(); for (int i = 1; i <= columncount; i++) { string columnname = metadata.getcolumnlabel(i); row.put(columnname, rs.getobject(i)); } return row; }); return createsuccessresponse(result); } else { // 更新操作 int affectedrows = jdbctemplate.update(sql, params.toarray()); return createsuccessresponse(collections.singletonmap("affectedrows", affectedrows)); } } catch (exception e) { logger.error("sql执行错误: {}", e.getmessage(), e); return createerrorresponse("sql执行错误: " + e.getmessage()); } } @postmapping("/executesql") public map<string, object> executesql(@requestbody sqlrequest request) { try { string sql = request.getsql(); list<object> params = request.getparams(); if (sql.trim().touppercase().startswith("select")) { // 查询操作 - 返回列和行数据 return handlequery(sql, params); } else { // 更新操作 - 返回受影响行数 return handleupdate(sql, params); } } catch (exception e) { logger.error("sql执行错误: {}", e.getmessage(), e); return createerrorresponse("sql执行错误: " + e.getmessage()); } } /** * 获取数据库所有表名 * @return 表名列表 */ @getmapping("/gettables") public map<string, object> getdatabasetables() { try { return jdbctemplate.execute((connectioncallback<map<string, object>>) connection -> { databasemetadata metadata = connection.getmetadata(); // 获取所有表名(不包含系统表) resultset tables = metadata.gettables( null, null, null, new string[]{"table"}); list<string> tablenames = new arraylist<>(); while (tables.next()) { string tablename = tables.getstring("table_name"); tablenames.add(tablename); } // 按字母顺序排序 collections.sort(tablenames); // 构建响应 map<string, object> response = new linkedhashmap<>(); response.put("success", true); response.put("data", tablenames); return response; }); } catch (exception e) { logger.error("获取数据库表失败: {}", e.getmessage(), e); map<string, object> errorresponse = new linkedhashmap<>(); errorresponse.put("success", false); errorresponse.put("message", "获取数据库表失败: " + e.getmessage()); return errorresponse; } } private map<string, object> handlequery(string sql, list<object> params) { try { return jdbctemplate.query(sql, params.toarray(), (resultsetextractor<map<string, object>>) rs -> { resultsetmetadata metadata = rs.getmetadata(); int columncount = metadata.getcolumncount(); // 获取列名 list<string> columns = new arraylist<>(); for (int i = 1; i <= columncount; i++) { columns.add(metadata.getcolumnlabel(i)); } // 获取行数据 list<list<object>> rows = new arraylist<>(); while (rs.next()) { list<object> row = new arraylist<>(); for (int i = 1; i <= columncount; i++) { row.add(rs.getobject(i)); } rows.add(row); } // 构建响应 map<string, object> data = new linkedhashmap<>(); data.put("columns", columns); data.put("rows", rows); map<string, object> response = new linkedhashmap<>(); response.put("success", true); response.put("data", data); return response; }); } catch (exception e) { logger.error("查询处理失败: {}", e.getmessage(), e); return createerrorresponse("查询处理失败: " + e.getmessage()); } } private map<string, object> handleupdate(string sql, list<object> params) { int affectedrows = jdbctemplate.update(sql, params.toarray()); map<string, object> data = new linkedhashmap<>(); data.put("affectedrows", affectedrows); map<string, object> response = new linkedhashmap<>(); response.put("success", true); response.put("data", data); return response; } // 创建成功响应 private map<string, object> createsuccessresponse(object data) { map<string, object> response = new linkedhashmap<>(); response.put("success", true); response.put("timestamp", system.currenttimemillis()); response.put("data", data); return response; } // 创建错误响应 private map<string, object> createerrorresponse(string message) { map<string, object> response = new linkedhashmap<>(); response.put("success", false); response.put("timestamp", system.currenttimemillis()); response.put("message", message); return response; } public static class sqlrequest { private string sql; private list<object> params = new arraylist<>(); // getters and setters public string getsql() { return sql; } public void setsql(string sql) { this.sql = sql; } public list<object> getparams() { return params; } public void setparams(list<object> params) { this.params = params; } } }
后端采用策略模式实现sql路由,自动区分查询与更新操作。通过jdbc元数据接口实现数据库自发现能力,为前端提供结构化数据支撑。
前端创新交互:
<template> <!-- 双面板设计 --> <div class="editor-container"> <!-- 元数据导航区 --> <div class="sidebar"> <div v-for="table in tables" @click="selecttable(table)"> <i class="fas fa-table"></i> {{ table }} </div> </div> <!-- sql工作区 --> <textarea v-model="sqlquery" @keydown.ctrl.enter="executesql"></textarea> <!-- 智能结果渲染 --> <el-table :data="result.data.rows"> <el-table-column v-for="(column, index) in result.data.columns" :label="column"> <template v-slot="scope"> <span v-if="scope.row[index] === null" class="null-value">null</span> <span v-else-if="typeof scope.row[index] === 'object'" @click="showjsondetail(scope.row[index])"> {{ jsonpreview(scope.row[index]) }} </span> </template> </el-table-column> </el-table> </div> </template>
前端实现三区域布局:元数据导航、sql编辑器和智能结果面板。采用动态类型检测技术,对null值、json对象等特殊数据类型进行可视化区分处理。
核心技术亮点
实时元数据发现
- 自动加载数据库表结构
- 表名智能排序与即时搜索
- 点击表名自动生成select模板
智能sql处理
// sql执行核心逻辑 async executesql() { const paginatedsql = this.addpagination(this.sqlquery); const response = await executesql(paginatedsql); // 高级结果处理 if (response.success) { this.result = { ...response, data: { ...response.data, executiontime: date.now() - starttime } } } }
- 自动分页机制
- 执行耗时精准统计
- 语法错误实时反馈
历史版本管理
// 历史记录管理 addtohistory(sql) { if (this.history.includes(sql)) return; this.history.unshift(sql); localstorage.setitem('sqlhistory', json.stringify(this.history)); }
本地存储自动持久化
智能去重机制
一键恢复历史查询
数据可视化增强
- json对象折叠预览
- null值特殊标识
- 分页控件动态加载
性能优化策略
查询优化
- 自动追加limit子句
- 分页查询按需加载
- 结果集流式处理
缓存机制
// 表结构缓存 async fetchdatabasetables() { if (this.cachedtables) return this.cachedtables; const response = await fetchtables(); this.cachedtables = response.data; }
完整vue代码:
<template> <div class="sql-executor-container"> <!-- 头部 --> <header> <div class="logo"> <i class="fas fa-database logo-icon"></i> <div> <h1>sql 执行工具</h1> <p>网页版数据库客户端工具</p> </div> </div> <div class="connection-info"> <i class="fas fa-plug"></i> 已连接到 {{ connectionname }} 数据库 </div> </header> <!-- 主体内容 --> <div class="main-content"> <!-- 侧边栏 --> <div class="sidebar"> <div class="sidebar-section"> <h3>数据库表</h3> <div v-for="table in tables" :key="table" class="schema-item" :class="{ active: selectedtable === table }" @click="selecttable(table)" > <i class="fas fa-table"></i> {{ table }} </div> </div> <div class="sidebar-section"> <h3>历史查询</h3> <div v-for="(query, index) in history" :key="index" class="schema-item history-item" @click="loadhistoryquery(query)" > <i class="fas fa-history"></i> {{ query.substring(0, 40) }}{{ query.length > 40 ? '...' : '' }} </div> </div> </div> <!-- 编辑器区域 --> <div class="editor-container"> <div class="sql-editor-container"> <div class="sql-editor-header"> <h2>sql 编辑器</h2> <div class="toolbar"> <el-button class="toolbar-btn run" @click="executesql" :loading="loading" > <i class="fas fa-play"></i> 执行 </el-button> <el-button class="toolbar-btn format" @click="formatsql" > <i class="fas fa-indent"></i> 格式化 </el-button> <el-button class="toolbar-btn clear" @click="cleareditor" > <i class="fas fa-trash-alt"></i> 清除 </el-button> </div> </div> <textarea class="sql-editor" v-model="sqlquery" placeholder="输入 sql 语句,例如:select * from table_name" @keydown.ctrl.enter="executesql" ></textarea> </div> <!-- 结果区域 --> <div class="result-container"> <div class="result-header"> <h2>执行结果</h2> <div class="result-info"> <div class="result-status" :class="result.success ? 'status-success' : 'status-error'" v-if="result" > {{ result.success ? '执行成功' : '执行失败' }} </div> <div class="rows-count" v-if="result && result.success"> 共 {{ result.data.total }} 行数据 (显示 {{ result.data.rows.length }} 行) </div> <div class="execution-time" v-if="result && result.success"> <i class="fas fa-clock"></i> {{ result.data.executiontime }} ms </div> </div> </div> <div class="result-content"> <!-- 加载状态 --> <div v-if="loading" class="no-data"> <i class="el-icon-loading" style="font-size: 48px;"></i> <p>正在执行查询...</p> </div> <!-- 查询结果 --> <div v-else-if="result && result.success && result.data.rows.length > 0" class="table-container"> <div class="table-wrapper"> <el-table :data="result.data.rows" height="100%" style="width: 100%" stripe border size="small" :default-sort = "{prop: 'id', order: 'ascending'}" > <el-table-column v-for="(column, index) in result.data.columns" :key="index" :prop="'row.' + index" :label="column" min-width="150" > <!-- <template slot-scope="scope"> <span v-if="scope.row[column] === null" class="null-value">null</span> <span v-else-if="typeof scope.row[column] === 'object'" class="json-value" @click="showjsondetail(scope.row[column])"> {{ jsonpreview(scope.row[column]) }} </span> <span v-else>{{ scope.row[column] }}</span> </template>--> <template slot-scope="scope"> <span v-if="scope.row[index] === null" class="null-value">null</span> <span v-else-if="typeof scope.row[index] === 'object'" class="json-value" @click="showjsondetail(scope.row[index])"> {{ jsonpreview(scope.row[index]) }} </span> <span v-else>{{ scope.row[index] }}</span> </template> </el-table-column> </el-table> </div> <!-- 分页控件 --> <el-pagination v-if="result.data.total > pagesize" @size-change="handlesizechange" @current-change="handlecurrentchange" :current-page="currentpage" :page-sizes="[10, 20, 50, 100]" :page-size="pagesize" layout="total, sizes, prev, pager, next, jumper" :total="result.data.total" class="pagination" > </el-pagination> </div> <!-- 空结果 --> <div v-else-if="result && result.success && result.data.rows.length === 0" class="no-data"> <i class="el-icon-inbox" style="font-size: 48px;"></i> <p>未查询到数据</p> </div> <!-- 错误信息 --> <div v-else-if="result && !result.success" class="error-container"> <div class="error-header"> <i class="el-icon-warning-outline" style="font-size: 20px;"></i> <h3>sql 执行错误</h3> </div> <div class="error-details"> {{ result.message }} </div> </div> <!-- 初始状态 --> <div v-else class="no-data"> <i class="el-icon-document" style="font-size: 48px;"></i> <p>输入 sql 并执行以查看结果</p> </div> </div> </div> </div> </div> <!-- 页脚 --> <div class="footer"> <div class="copyright"> © {{ new date().getfullyear() }} sql执行工具 - 网页版数据库客户端 </div> <div class="shortcuts"> <div class="shortcut-item"> <span class="key">ctrl</span> + <span class="key">enter</span> 执行查询 </div> <div class="shortcut-item"> <span class="key">ctrl</span> + <span class="key">/</span> 格式化 sql </div> </div> </div> <!-- json 详情弹窗 --> <el-dialog title="json 详情" :visible.sync="showjsonmodal" width="70%" top="5vh" > <pre class="json-content">{{ formatjson(currentjson) }}</pre> <span slot="footer" class="dialog-footer"> <el-button type="primary" @click="showjsonmodal = false">关 闭</el-button> </span> </el-dialog> </div> </template> <script> import { fetchtables, executesql } from '@/api/sqlutil/sqlutil'; export default { name: 'sqlutil', data() { return { sqlquery: '', result: null, loading: false, tables: [], selectedtable: null, history: [], showjsonmodal: false, currentjson: null, connectionname: '生产', currentpage: 1, pagesize: 20 } }, mounted() { // 从本地存储加载历史记录 const savedhistory = localstorage.getitem('sqlhistory'); if (savedhistory) { this.history = json.parse(savedhistory); } // 获取当前连接信息 this.getconnectioninfo(); // 获取数据库表 this.fetchdatabasetables(); }, methods: { async fetchdatabasetables() { try { this.loading = true; const response = await fetchtables(); this.tables = response.data || []; if (this.tables.length > 0) { this.selectedtable = this.tables[0]; this.sqlquery = `select * from ${this.selectedtable}`; } } catch (error) { console.error('获取数据库表失败:', error); this.$message.error('获取数据库表失败: ' + error.message); } finally { this.loading = false; } }, async executesql() { if (!this.sqlquery.trim()) { this.result = { success: false, message: 'sql 语句不能为空' }; return; } this.loading = true; this.result = null; try { // 添加分页参数 const paginatedsql = this.addpagination(this.sqlquery); const response = await executesql(paginatedsql); this.result = response; // 保存到历史记录 this.addtohistory(this.sqlquery); } catch (error) { this.result = { success: false, message: `请求失败: ${error.message || error}` }; } finally { this.loading = false; } }, // 添加分页到sql addpagination(sql) { // 如果是select查询,添加分页 /*if (sql.trim().touppercase().startswith('select')) { const offset = (this.currentpage - 1) * this.pagesize; return `${sql} limit ${offset}, ${this.pagesize}`; }*/ return sql; }, handlesizechange(val) { this.pagesize = val; this.currentpage = 1; if (this.sqlquery.trim()) { this.executesql(); } }, handlecurrentchange(val) { this.currentpage = val; if (this.sqlquery.trim()) { this.executesql(); } }, // 获取数据库连接信息 getconnectioninfo() { // 这里可以根据实际情况从api获取或从配置读取 const env = process.env.node_env; this.connectionname = env === 'production' ? '生产' : env === 'staging' ? '预发布' : '开发'; }, formatsql() { // 简单的 sql 格式化 this.sqlquery = this.sqlquery .replace(/\b(select|from|where|and|or|order by|group by|having|insert|update|delete|join|inner join|left join|right join|on|as|limit)\b/gi, '\n$1') .replace(/,/g, ',\n') .replace(/;/g, ';\n') .replace(/\n\s+\n/g, '\n') .trim(); }, cleareditor() { this.sqlquery = ''; this.result = null; }, selecttable(table) { this.selectedtable = table; this.sqlquery = `select * from ${table} limit 100`; }, addtohistory(sql) { // 避免重复添加 if (this.history.includes(sql)) return; this.history.unshift(sql); // 限制历史记录数量 if (this.history.length > 10) { this.history.pop(); } // 保存到本地存储 localstorage.setitem('sqlhistory', json.stringify(this.history)); }, loadhistoryquery(sql) { this.sqlquery = sql; }, jsonpreview(obj) { try { const str = json.stringify(obj); return str.length > 50 ? str.substring(0, 47) + '...' : str; } catch { return '[object]'; } }, showjsondetail(obj) { this.currentjson = obj; this.showjsonmodal = true; }, formatjson(obj) { return json.stringify(obj, null, 2); } } } </script> <style scoped> .sql-executor-container { display: flex; flex-direction: column; height: 100vh; max-width: 100%; margin: 0 auto; background-color: rgba(255, 255, 255, 0.95); overflow: hidden; } header { background: linear-gradient(90deg, #2c3e50, #4a6491); color: white; padding: 15px 30px; display: flex; justify-content: space-between; align-items: center; flex-shrink: 0; } .logo { display: flex; align-items: center; gap: 15px; } .logo-icon { font-size: 28px; color: #42b983; } .logo h1 { font-weight: 600; font-size: 22px; } .logo p { opacity: 0.8; font-size: 13px; margin-top: 4px; } .connection-info { background: rgba(255, 255, 255, 0.1); padding: 8px 15px; border-radius: 20px; font-size: 13px; } .main-content { display: flex; flex: 1; min-height: 0; overflow: hidden; } .sidebar { width: 260px; background: #f8f9fa; border-right: 1px solid #eaeaea; padding: 15px 0; overflow-y: auto; flex-shrink: 0; } .sidebar-section { margin-bottom: 20px; } .sidebar-section h3 { padding: 0 20px 10px; font-size: 16px; color: #4a5568; border-bottom: 1px solid #eaeaea; margin-bottom: 12px; } .schema-item { padding: 8px 20px 8px 35px; cursor: pointer; transition: all 0.2s; position: relative; font-size: 14px; display: flex; align-items: center; gap: 8px; } .schema-item i { font-size: 14px; width: 20px; } .schema-item:hover { background: #e9ecef; } .schema-item.active { background: #e3f2fd; color: #1a73e8; font-weight: 500; } .history-item { font-size: 13px; color: #666; } .editor-container { flex: 1; display: flex; flex-direction: column; min-width: 0; overflow: hidden; } .sql-editor-container { flex: 0 0 40%; display: flex; flex-direction: column; border-bottom: 1px solid #eaeaea; min-height: 200px; overflow: hidden; } .sql-editor-header { padding: 12px 20px; background: #f1f3f4; display: flex; justify-content: space-between; align-items: center; border-bottom: 1px solid #eaeaea; flex-shrink: 0; } .sql-editor-header h2 { font-size: 17px; color: #2d3748; } .toolbar { display: flex; gap: 8px; } .toolbar-btn { padding: 7px 12px; border: none; border-radius: 6px; background: #4a6491; color: white; cursor: pointer; display: flex; align-items: center; gap: 5px; font-size: 13px; transition: all 0.2s; } .toolbar-btn:hover { opacity: 0.9; transform: translatey(-1px); } .toolbar-btn i { font-size: 13px; } .toolbar-btn.run { background: #42b983; } .toolbar-btn.format { background: #f0ad4e; } .toolbar-btn.clear { background: #e74c3c; } .sql-editor { flex: 1; padding: 15px; font-family: 'fira code', 'consolas', monospace; font-size: 14px; line-height: 1.5; border: none; resize: none; outline: none; background: #fcfcfc; min-height: 100px; overflow: auto; } .result-container { flex: 1; display: flex; flex-direction: column; min-height: 0; overflow: hidden; } .result-header { padding: 12px 20px; background: #f1f3f4; display: flex; justify-content: space-between; align-items: center; border-bottom: 1px solid #eaeaea; flex-shrink: 0; } .result-header h2 { font-size: 17px; color: #2d3748; } .result-info { display: flex; align-items: center; gap: 15px; font-size: 13px; } .result-status { padding: 4px 10px; border-radius: 20px; font-size: 13px; font-weight: 500; } .status-success { background: #e8f5e9; color: #2e7d32; } .status-error { background: #ffebee; color: #c62828; } .rows-count, .execution-time { color: #5f6368; display: flex; align-items: center; gap: 4px; } .result-content { flex: 1; overflow: auto; position: relative; min-height: 0; } .table-container { display: flex; flex-direction: column; height: 100%; } .table-wrapper { flex: 1; overflow: auto; min-height: 200px; } .el-table { width: 100%; min-width: 1000px; } .pagination { padding: 10px 15px; border-top: 1px solid #ebeef5; background: #fff; display: flex; justify-content: flex-end; } .null-value { color: #b0b0b0; font-style: italic; } .json-value { color: #d35400; cursor: pointer; text-decoration: underline dotted; } .no-data { position: absolute; top: 50%; left: 50%; transform: translate(-50%, -50%); text-align: center; color: #909399; font-size: 14px; } .error-container { padding: 20px; background-color: #ffebee; border-radius: 8px; margin: 20px; color: #c62828; } .error-header { display: flex; align-items: center; gap: 10px; margin-bottom: 10px; } .error-details { font-family: monospace; font-size: 14px; white-space: pre-wrap; background: rgba(255, 255, 255, 0.7); padding: 15px; border-radius: 6px; margin-top: 10px; overflow-x: auto; } .footer { padding: 12px 30px; background: #f8f9fa; border-top: 1px solid #eaeaea; display: flex; justify-content: space-between; align-items: center; font-size: 12px; color: #6c757d; flex-shrink: 0; } .shortcuts { display: flex; gap: 15px; } .shortcut-item { display: flex; align-items: center; gap: 5px; } .key { background: #e9ecef; padding: 3px 8px; border-radius: 4px; font-weight: 500; font-size: 11px; } .json-content { background: #f8f8f8; padding: 15px; border-radius: 4px; max-height: 70vh; overflow: auto; font-family: monospace; line-height: 1.5; font-size: 14px; } @media (max-width: 992px) { .main-content { flex-direction: column; } .sidebar { width: 100%; border-right: none; border-bottom: 1px solid #eaeaea; height: 200px; overflow: auto; } .result-info { flex-wrap: wrap; gap: 8px; } } @media (max-width: 768px) { header { flex-direction: column; gap: 10px; text-align: center; } .logo { flex-direction: column; gap: 5px; } .connection-info { margin-top: 5px; } .toolbar { flex-wrap: wrap; justify-content: center; } .footer { flex-direction: column; gap: 10px; } } </style>
import request from '@/utils/request' export function executesql(sql) { return request({ url: '/sqlutil/executesql', method: 'post', data: { sql: sql } }) } export function fetchtables() { return request({ url: '/sqlutil/gettables', method: 'get' }) }
import {message} from 'element-ui' import axios from 'axios' axios.defaults.headers.post['content-type'] = 'application/json;charset=utf-8' import store from "@/store"; import router from '@/router'; // create an axios instance const service = axios.create({ baseurl: `http://127.0.0.1:8080`, timeout: 75000, }) export default service
效果:
总结
该sql执行工具通过四大创新设计重塑了数据库交互体验:
- 元数据驱动:将数据库结构转化为可视化导航
- 上下文感知:自动识别sql类型并优化执行
- 渐进式渲染:平衡大数据量与用户体验
- 历史时空隧道:完整记录操作轨迹
