Android Bugreport实现原理深入分析

// packages/modules/adb/client/main.cpp
int main(int argc, char* argv[], char* envp[]) {
    __adb_argv = const_cast<const char**>(argv);
    __adb_envp = const_cast<const char**>(envp);
    adb_trace_init(argv);
    return adb_commandline(argc - 1, const_cast<const char**>(argv + 1));
}
// packages/modules/adb/client/commandline.cpp
int adb_commandline(int argc, const char** argv) {
        // 省略
    /* adb_connect() commands */
    if (!strcmp(argv[0], "devices")) {
                // 省略
    } else if (!strcmp(argv[0], "bugreport")) {
        bugreport bugreport;
        return bugreport.doit(argc, argv);
    } else if (!strcmp(argv[0], "forward") || !strcmp(argv[0], "reverse")) {
    // 省略
}

int bugreport::doit(int argc, const char** argv) {
    if (argc > 2) error_exit("usage: adb bugreport [[path] | [--stream]]");
    // gets bugreportz version.
    std::string bugz_stdout, bugz_stderr;
    defaultstandardstreamscallback version_callback(&bugz_stdout, &bugz_stderr);
    int status = sendshellcommand("bugreportz -v", false, &version_callback);
    std::string bugz_version = android::base::trim(bugz_stderr);
    std::string bugz_output = android::base::trim(bugz_stdout);
    int bugz_ver_major = 0, bugz_ver_minor = 0;
    if (status != 0 || bugz_version.empty()) {
        d("'bugreportz' -v results: status=%d, stdout='%s', stderr='%s'", status,
          bugz_output.c_str(), bugz_version.c_str());
        if (argc == 1) {
            // device does not support bugreportz: if called as 'adb bugreport', just falls out to
            // the flat-file version.
            fprintf(stderr,
                    "failed to get bugreportz version, which is only available on devices "
                    "running android 7.0 or later.\ntrying a plain-text bug report instead.\n");
            return sendshellcommand("bugreport", false);
        }
        // but if user explicitly asked for a zipped bug report, fails instead (otherwise calling
        // 'bugreport' would generate a lot of output the user might not be prepared to handle).
        fprintf(stderr,
                "failed to get bugreportz version: 'bugreportz -v' returned '%s' (code %d).\n"
                "if the device does not run android 7.0 or above, try this instead:\n"
                "\tadb bugreport > bugreport.txt\n",
                bugz_output.c_str(), status);
        return status != 0 ? status : -1;
    }
    std::sscanf(bugz_version.c_str(), "%d.%d", &bugz_ver_major, &bugz_ver_minor);
    std::string dest_file, dest_dir;
    if (argc == 1) {
        // no args - use current directory
        if (!getcwd(&dest_dir)) {
            perror("adb: getcwd failed");
            return 1;
        }
    } else if (!strcmp(argv[1], "--stream")) {
        if (bugz_ver_major == 1 && bugz_ver_minor < 2) {
            fprintf(stderr,
                    "failed to stream bugreport: bugreportz does not support stream.\n");
        } else {
            return sendshellcommand("bugreportz -s", false);
        }
    } else {
        // check whether argument is a directory or file
        if (directory_exists(argv[1])) {
            dest_dir = argv[1];
        } else {
            dest_file = argv[1];
        }
    }
    if (dest_file.empty()) {
        // uses a default value until device provides the proper name
        dest_file = "bugreport.zip";
    } else {
        if (!android::base::endswithignorecase(dest_file, ".zip")) {
            dest_file += ".zip";
        }
    }
    bool show_progress = true;
    std::string bugz_command = "bugreportz -p";
    if (bugz_version == "1.0") {
        // 1.0 does not support progress notifications, so print a disclaimer
        // message instead.
        fprintf(stderr,
                "bugreport is in progress and it could take minutes to complete.\n"
                "please be patient and do not cancel or disconnect your device "
                "until it completes.\n");
        show_progress = false;
        bugz_command = "bugreportz";
    }
    bugreportstandardstreamscallback bugz_callback(dest_dir, dest_file, show_progress, this);
    return sendshellcommand(bugz_command, false, &bugz_callback);
}

// frameworks/native/cmds/bugreportz/main.cpp
static constexpr char version[] = "1.2";
static void show_usage() {
    fprintf(stderr,
            "usage: bugreportz [-hpsv]\n"
            "  -h: to display this help message\n"
            "  -p: display progress\n"
            "  -s: stream content to standard output\n"
            "  -v: to display the version\n"
            "  or no arguments to generate a zipped bugreport\n");
}
static void show_version() {
    fprintf(stderr, "%s\n", version);
}
int main(int argc, char* argv[]) {
    bool show_progress = false;
    bool stream_data = false;
    if (argc > 1) {
        /* parse arguments */
        int c;
        while ((c = getopt(argc, argv, "hpsv")) != -1) {
            switch (c) {
                case 'h':
                    show_usage();
                    return exit_success;
                case 'p':
                    show_progress = true;
                    break;
                case 's':
                    stream_data = true;
                    break;
                case 'v':
                    show_version();
                    return exit_success;
                default:
                    show_usage();
                    return exit_failure;
            }
        }
    }
    // we don't support any non-option arguments.
    if (optind != argc) {
        show_usage();
        return exit_failure;
    }
    // todo: code below was copy-and-pasted from bugreport.cpp (except by the
    // timeout value);
    // should be reused instead.
    // start the dumpstatez service.
    if (stream_data) {
        property_set("ctl.start", "dumpstate");
    } else {
        // 调用dumpstatez
        property_set("ctl.start", "dumpstatez");
    }
    // socket will not be available until service starts.
    int s = -1;
    for (int i = 0; i < 20; i++) {
        // 接连dumpstatez的socket（接收状态信息）
        s = socket_local_client("dumpstate", android_socket_namespace_reserved, sock_stream);
        if (s >= 0) break;
        // try again in 1 second.
        sleep(1);
    }
    if (s == -1) {
        printf("fail:failed to connect to dumpstatez service: %s\n", strerror(errno));
        return exit_failure;
    }
    // set a timeout so that if nothing is read in 10 minutes, we'll stop
    // reading and quit. no timeout in dumpstate is longer than 60 seconds,
    // so this gives lots of leeway in case of unforeseen time outs.
    struct timeval tv;
    tv.tv_sec = 10 * 60;
    tv.tv_usec = 0;
    if (setsockopt(s, sol_socket, so_rcvtimeo, &tv, sizeof(tv)) == -1) {
        fprintf(stderr,
                "warning: cannot set socket timeout, bugreportz might hang indefinitely: %s\n",
                strerror(errno));
    }
    int ret;
    if (stream_data) {
        ret = bugreportz_stream(s);
    } else {
        // 走这里，show_progress为true
        ret = bugreportz(s, show_progress);
    }
    if (close(s) == -1) {
        fprintf(stderr, "warning: error closing socket: %s\n", strerror(errno));
        ret = exit_failure;
    }
    return ret;
}

static constexpr char begin_prefix[] = "begin:";
static constexpr char progress_prefix[] = "progress:";
static void write_line(const std::string& line, bool show_progress) {    if (line.empty()) return;
    // when not invoked with the -p option, it must skip begin and progress lines otherwise it// will break adb (which is expecting either ok or fail).if (!show_progress && (android::base::startswith(line, progress_prefix) ||
                           android::base::startswith(line, begin_prefix)))
        return;
    android::base::writestringtofd(line, stdout_fileno);
}
int bugreportz(int s, bool show_progress) {    std::string line;
    while (1) {
        char buffer[65536];
        ssize_t bytes_read = temp_failure_retry(read(s, buffer, sizeof(buffer)));
        if (bytes_read == 0) {
            break;
        } else if (bytes_read == -1) {
            // eagain really means time out, so change the errno.if (errno == eagain) {
                errno = etimedout;
            }
            printf("fail:bugreport read terminated abnormally (%s)\n", strerror(errno));
            return exit_failure;
        }
        // writes line by line.for (int i = 0; i < bytes_read; i++) {
            char c = buffer[i];
            line.append(1, c);
            if (c == '\n') {
                write_line(line, show_progress);
                line.clear();
            }
        }
    }
    // process final line, in case it didn't finish with newlinewrite_line(line, show_progress);
    return exit_success;
}

// frameworks/native/cmds/dumpstate/main.cpp
int main(int argc, char* argv[]) {
    if (shouldstartserviceandwait(argc, argv)) {
        int ret;
        if ((ret = android::os::dumpstateservice::start()) != android::ok) {
            myloge("unable to start 'dumpstate' service: %d", ret);
            exit(1);
        }
        mylogi("'dumpstate' service started and will wait for a call to startbugreport()");
        // waits forever for an incoming connection.
        // todo(b/111441001): should this time out?
        android::ipcthreadstate::self()->jointhreadpool();
        return 0;
    } else {
        return run_main(argc, argv);
    }
}
// frameworks/native/cmds/dumpstate/dumpstate.cpp
/* main entry point for dumpstate binary. */
int run_main(int argc, char* argv[]) {
    dumpstate::runstatus status = ds.parsecommandlineandrun(argc, argv);
    switch (status) {
        case dumpstate::runstatus::ok:
            exit(0);
        case dumpstate::runstatus::help:
            showusage();
            exit(0);
        case dumpstate::runstatus::invalid_input:
            fprintf(stderr, "invalid combination of args\n");
            showusage();
            exit(1);
        case dumpstate::runstatus::error:
            fallthrough_intended;
        case dumpstate::runstatus::user_consent_denied:
            fallthrough_intended;
        case dumpstate::runstatus::user_consent_timed_out:
            exit(2);
    }
}
dumpstate::runstatus dumpstate::parsecommandlineandrun(int argc, char* argv[]) {
    std::unique_ptr<dumpstate::dumpoptions> options = std::make_unique<dumpstate::dumpoptions>();
    dumpstate::runstatus status = options->initialize(argc, argv);
    if (status == dumpstate::runstatus::ok) {
        setoptions(std::move(options));
        // when directly running dumpstate binary, the output is not expected to be written
        // to any external file descriptor.
        assert(options_->bugreport_fd.get() == -1);
        // calling_uid and calling_package are for user consent to share the bugreport with
        // an app; they are irrelevant here because bugreport is triggered via command line.
        // update last id before calling run().
        initialize();
        status = run(-1 /* calling_uid */, "" /* calling_package */);
    }
    return status;
}

void dumpstate::dumpoptions::initialize(bugreportmode bugreport_mode,
                                        const android::base::unique_fd& bugreport_fd_in,
                                        const android::base::unique_fd& screenshot_fd_in,
                                        bool is_screenshot_requested) {
    // duplicate the fds because the passed in fds don't outlive the binder transaction.
    bugreport_fd.reset(dup(bugreport_fd_in.get()));
    screenshot_fd.reset(dup(screenshot_fd_in.get()));
    setoptionsfrommode(bugreport_mode, this, is_screenshot_requested);
}
dumpstate::runstatus dumpstate::dumpoptions::initialize(int argc, char* argv[]) {
    runstatus status = runstatus::ok;
    int c;
    while ((c = getopt(argc, argv, "dho:svqzplpbrsv:w")) != -1) {
        switch (c) {
            // clang-format off
            case 'o': out_dir = optarg;              break;
            case 's': stream_to_socket = true;       break;
            case 's': progress_updates_to_socket = true;    break;
            case 'v': show_header_only = true;       break;
            case 'q': do_vibrate = false;            break;
            case 'p': do_screenshot = true;          break;
            case 'p': do_progress_updates = true;    break;
            case 'r': is_remote_mode = true;         break;
            case 'l': limited_only = true;           break;
            case 'v':
            case 'd':
            case 'z':
                // compatibility no-op
                break;
            case 'w':
                // this was already processed
                break;
            case 'h':
                status = runstatus::help;
                break;
            default:
                fprintf(stderr, "invalid option: %c\n", c);
                status = runstatus::invalid_input;
                break;
                // clang-format on
        }
    }
    for (int i = 0; i < argc; i++) {
        args += argv[i];
        if (i < argc - 1) {
            args += " ";
        }
    }
    // reset next index used by getopt so this can be called multiple times, for eg, in tests.
    optind = 1;
    return status;
}

void dumpstate::initialize() {
    /* gets the sequential id */
    uint32_t last_id = android::base::getintproperty(property_last_id, 0);
    id_ = ++last_id;
    android::base::setproperty(property_last_id, std::to_string(last_id));
}
dumpstate::runstatus dumpstate::run(int32_t calling_uid, const std::string& calling_package) {
    dumpstate::runstatus status = runinternal(calling_uid, calling_package);
    if (listener_ != nullptr) {
        switch (status) {
            case dumpstate::runstatus::ok:
                listener_->onfinished();
                break;
            case dumpstate::runstatus::help:
                break;
            case dumpstate::runstatus::invalid_input:
                listener_->onerror(idumpstatelistener::bugreport_error_invalid_input);
                break;
            case dumpstate::runstatus::error:
                listener_->onerror(idumpstatelistener::bugreport_error_runtime_error);
                break;
            case dumpstate::runstatus::user_consent_denied:
                listener_->onerror(idumpstatelistener::bugreport_error_user_denied_consent);
                break;
            case dumpstate::runstatus::user_consent_timed_out:
                listener_->onerror(idumpstatelistener::bugreport_error_user_consent_timed_out);
                break;
        }
    }
    return status;
}

dumpstate::runstatus dumpstate::runinternal(int32_t calling_uid,
                                            const std::string& calling_package) {
    durationreporter duration_reporter("run internal", /* logcat_only = */true);
    logdumpoptions(*options_);
    if (!options_->validateoptions()) {
        myloge("invalid options specified\n");
        return runstatus::invalid_input;
    }
    /* set as high priority, and protect from oom killer */
    setpriority(prio_process, 0, -20);
    file* oom_adj = fopen("/proc/self/oom_score_adj", "we");
    if (oom_adj) {
        fputs("-1000", oom_adj);
        fclose(oom_adj);
    } else {
        /* fallback to kernels <= 2.6.35 */
        oom_adj = fopen("/proc/self/oom_adj", "we");
        if (oom_adj) {
            fputs("-17", oom_adj);
            fclose(oom_adj);
        }
    }
    mylogi("dumpstate info: id=%d, args='%s', bugreport_mode= %s bugreport format version: %s\n",
           id_, options_->args.c_str(), options_->bugreport_mode.c_str(), version_.c_str());
    // if we are going to use a socket, do it as early as possible
    // to avoid timeouts from bugreport.
    if (options_->stream_to_socket || options_->progress_updates_to_socket) {
        mylogd("opening control socket\n");
        control_socket_fd_ = open_socket_fn_("dumpstate");
        if (control_socket_fd_ == -1) {
            return error;
        }
        if (options_->progress_updates_to_socket) {
            options_->do_progress_updates = 1;
        }
    }
    // 准备文件
    if (!preparetowritetofile()) {
        return error;
    }
    // 将标准输出，重定向到临时文件bugreport-*.tmp文件中
    // 通过bugreport-*.tmp文件，产生最终的bugreport-*.zip
    // redirect stdout to tmp_path_. this is the main bugreport entry and will be
    // moved into zip file later, if zipping.
    temp_failure_retry(dup_stdout_fd = dup(fileno(stdout)));
    // todo: why not write to a file instead of stdout to overcome this problem?
    /* todo: rather than generating a text file now and zipping it later,
        it would be more efficient to redirect stdout to the zip entry
        directly, but the libziparchive doesn't support that option yet. */
    if (!redirect_to_file(stdout, const_cast<char*>(tmp_path_.c_str()))) {
        return error;
    }
    if (chown(tmp_path_.c_str(), aid_shell, aid_shell)) {
        myloge("unable to change ownership of temporary bugreport file %s: %s\n",
                tmp_path_.c_str(), strerror(errno));
    }
    // 输出头部分信息（就是bugreport-*.txt最开头的一些版本信息)
    // note: there should be no stdout output until now, otherwise it would break the header.
    // in particular, durationreport objects should be created passing 'title, null', so their
    // duration is logged into mylog instead.
    printheader();
    bool is_dumpstate_restricted = options_->telephony_only
                                   || options_->wifi_only
                                   || options_->limited_only;
    if (!is_dumpstate_restricted) {
        // dump系统关键服务的状态
        // ------ dumpsys critical (/system/bin/dumpsys) ------的信息
        // invoke critical dumpsys first to preserve system state, before doing anything else.
        rundumpsyscritical();
    }
    if (options_->telephony_only) {
        dumpstatetelephonyonly(calling_package);
    } else if (options_->wifi_only) {
        dumpstatewifionly();
    } else if (options_->limited_only) {
        dumpstatelimitedonly();
    } else {
        // dump state for the default case. this also drops root.
        // dump额外信息
        runstatus s = dumpstatedefaultaftercritical();
        if (s != runstatus::ok) {
            if (s == runstatus::user_consent_denied) {
                handleuserconsentdenied();
            }
            return s;
        }
    }
    // 解除重定向
    /* close output if needed */
    temp_failure_retry(dup2(dup_stdout_fd, fileno(stdout)));
    // 完成zip的打包，删除临时文件
    // zip the (now complete) .tmp file within the internal directory.
    finalizefile();
        // 省略
}

/*
 * prepares state like filename, screenshot path, etc in dumpstate. also initializes zipwriter
 * and adds the version file. return false if zip_file could not be open to write.
 */
static bool preparetowritetofile() {
    mayberesolvesymlink(&ds.bugreport_internal_dir_);
    std::string build_id = android::base::getproperty("ro.build.id", "unknown_build");
    std::string device_name = android::base::getproperty("ro.product.name", "unknown_device");
    ds.base_name_ = stringprintf("bugreport-%s-%s", device_name.c_str(), build_id.c_str());
    char date[80];
    strftime(date, sizeof(date), "%y-%m-%d-%h-%m-%s", localtime(&ds.now_));
    ds.name_ = date;
    if (ds.options_->telephony_only) {
        ds.base_name_ += "-telephony";
    } else if (ds.options_->wifi_only) {
        ds.base_name_ += "-wifi";
    }
    if (ds.options_->do_screenshot) {
        ds.screenshot_path_ = ds.getpath(ds.calledbyapi() ? "-png.tmp" : ".png");
    }
    ds.tmp_path_ = ds.getpath(".tmp");
    ds.log_path_ = ds.getpath("-dumpstate_log-" + std::to_string(ds.pid_) + ".txt");
    std::string destination = ds.calledbyapi()
                                  ? stringprintf("[fd:%d]", ds.options_->bugreport_fd.get())
                                  : ds.bugreport_internal_dir_.c_str();
    mylogd(
        "bugreport dir: [%s] "
        "base name: [%s] "
        "suffix: [%s] "
        "log path: [%s] "
        "temporary path: [%s] "
        "screenshot path: [%s]\n",
        destination.c_str(), ds.base_name_.c_str(), ds.name_.c_str(), ds.log_path_.c_str(),
        ds.tmp_path_.c_str(), ds.screenshot_path_.c_str());
    ds.path_ = ds.getpath(ds.calledbyapi() ? "-zip.tmp" : ".zip");
    mylogd("creating initial .zip file (%s)\n", ds.path_.c_str());
    create_parent_dirs(ds.path_.c_str());
    ds.zip_file.reset(fopen(ds.path_.c_str(), "wb"));
    if (ds.zip_file == nullptr) {
        myloge("fopen(%s, 'wb'): %s\n", ds.path_.c_str(), strerror(errno));
        return false;
    }
    ds.zip_writer_.reset(new zipwriter(ds.zip_file.get()));
    ds.addtextzipentry("version.txt", ds.version_);
    return true;
}

void dumpstate::printheader() const {
    std::string build, fingerprint, radio, bootloader, network;
    char date[80];
    build = android::base::getproperty("ro.build.display.id", "(unknown)");
    fingerprint = android::base::getproperty("ro.build.fingerprint", "(unknown)");
    radio = android::base::getproperty("gsm.version.baseband", "(unknown)");
    bootloader = android::base::getproperty("ro.bootloader", "(unknown)");
    network = android::base::getproperty("gsm.operator.alpha", "(unknown)");
    strftime(date, sizeof(date), "%y-%m-%d %h:%m:%s", localtime(&now_));
    printf("========================================================\n");
    printf("== dumpstate: %s\n", date);
    printf("========================================================\n");
    printf("\n");
    printf("build: %s\n", build.c_str());
    // note: fingerprint entry format is important for other tools.
    printf("build fingerprint: '%s'\n", fingerprint.c_str());
    printf("bootloader: %s\n", bootloader.c_str());
    printf("radio: %s\n", radio.c_str());
    printf("network: %s\n", network.c_str());
    int64_t module_metadata_version = android::os::getmodulemetadataversion();
    if (module_metadata_version != 0) {
        printf("module metadata version: %" prid64 "\n", module_metadata_version);
    }
    printf("sdk extension versions [r=%s s=%s]\n",
           android::base::getproperty("build.version.extensions.r", "-").c_str(),
           android::base::getproperty("build.version.extensions.s", "-").c_str());
    printf("kernel: ");
    dumpfiletofd(stdout_fileno, "", "/proc/version");
    printf("command line: %s\n", strtok(cmdline_buf, "\n"));
    printf("uptime: ");
    runcommandtofd(stdout_fileno, "", {"uptime", "-p"},
                   commandoptions::withtimeout(1).always().build());
    printf("bugreport format version: %s\n", version_.c_str());
    printf("dumpstate info: id=%d pid=%d dry_run=%d parallel_run=%d args=%s bugreport_mode=%s\n",
           id_, pid_, propertieshelper::isdryrun(), propertieshelper::isparallelrun(),
           options_->args.c_str(), options_->bugreport_mode.c_str());
    printf("\n");
}

// frameworks/native/cmds/dumpstate/dumpstate.cpp
static void rundumpsystext(const std::string& title, int priority,                           std::chrono::milliseconds timeout,
                           std::chrono::milliseconds service_timeout) {
    durationreporter duration_reporter(title);
    dprintf(stdout_fileno, "------ %s (/system/bin/dumpsys) ------\n", title.c_str());
    fsync(stdout_fileno);
    rundumpsystextbypriority(title, priority, timeout, service_timeout);
}
static void rundumpsystext(const std::string& title, int priority,                           std::chrono::milliseconds timeout,
                           std::chrono::milliseconds service_timeout) {
    durationreporter duration_reporter(title);
    dprintf(stdout_fileno, "------ %s (/system/bin/dumpsys) ------\n", title.c_str());
    fsync(stdout_fileno);
    rundumpsystextbypriority(title, priority, timeout, service_timeout);
}
static dumpstate::runstatus rundumpsystextbypriority(const std::string& title, int priority,
                                                     std::chrono::milliseconds timeout,
                                                     std::chrono::milliseconds service_timeout) {
    auto start = std::chrono::steady_clock::now();
    sp<android::iservicemanager> sm = defaultservicemanager();
    dumpsys dumpsys(sm.get());
    vector<string16> args;
    dumpsys::setserviceargs(args, /* asproto = */ false, priority);
    vector<string16> services = dumpsys.listservices(priority, /* supports_proto = */ false);
    for (const string16& service : services) {
        return_if_user_denied_consent();
        std::string path(title);
        path.append(" - ").append(string8(service).c_str());
        size_t bytes_written = 0;
        // 在dumpthread中，调用service的dump
        status_t status = dumpsys.startdumpthread(dumpsys::type::dump, service, args);
        if (status == ok) {
            dumpsys.writedumpheader(stdout_fileno, service, priority);
            std::chrono::duration<double> elapsed_seconds;
            if (priority == iservicemanager::dump_flag_priority_high &&
                service == string16("meminfo")) {
                // use a longer timeout for meminfo, since 30s is not always enough.
                status = dumpsys.writedump(stdout_fileno, service, 60s,
                                           /* as_proto = */ false, elapsed_seconds, bytes_written);
            } else {
                status = dumpsys.writedump(stdout_fileno, service, service_timeout,
                                           /* as_proto = */ false, elapsed_seconds, bytes_written);
            }
            dumpsys.writedumpfooter(stdout_fileno, service, elapsed_seconds);
            bool dump_complete = (status == ok);
            dumpsys.stopdumpthread(dump_complete);
        }
        auto elapsed_duration = std::chrono::duration_cast<std::chrono::milliseconds>(
            std::chrono::steady_clock::now() - start);
        if (elapsed_duration > timeout) {
            myloge("*** command '%s' timed out after %llums\n", title.c_str(),
                   elapsed_duration.count());
            break;
        }
    }
    return dumpstate::runstatus::ok;
}

// frameworks/native/cmds/dumpstate/dumpstate.cpp
dumpstate::runstatus dumpstate::dumpstatedefaultaftercritical() {
    // capture first logcat early on; useful to take a snapshot before dumpstate logs take over the
    // buffer.
    dologcat();
    // capture timestamp after first logcat to use in next logcat
    time_t logcat_ts = time(nullptr);
    /* collect stack traces from dalvik and native processes (needs root) */
    if (dump_pool_) {
        return_if_user_denied_consent();
        // one thread is enough since we only need to enqueue dumptraces here.
        dump_pool_->start(/* thread_counts = */1);
        // dumptraces takes long time, post it to the another thread in the
        // pool, if pool is available
        dump_pool_->enqueuetask(dump_traces_task, &dumpstate::dumptraces, &ds, &dump_traces_path);
    } else {
        run_slow_function_with_consent_check_and_log(dump_traces_task, ds.dumptraces,
                &dump_traces_path);
    }
    /* run some operations that require root. */
    ds.tombstone_data_ = getdumpfds(tombstone_dir, tombstone_file_prefix, !ds.iszipping());
    ds.anr_data_ = getdumpfds(anr_dir, anr_file_prefix, !ds.iszipping());
    ds.adddir(recovery_dir, true);
    ds.adddir(recovery_data_dir, true);
    ds.adddir(update_engine_log_dir, true);
    ds.adddir(logpersist_data_dir, false);
    if (!propertieshelper::isuserbuild()) {
        ds.adddir(profile_data_dir_cur, true);
        ds.adddir(profile_data_dir_ref, true);
        ds.addzipentry(zip_root_dir + package_dex_use_list, package_dex_use_list);
    }
    ds.adddir(prereboot_data_dir, false);
    add_mountinfo();
    dumpiptablesasroot();
    dumpdynamicpartitioninfo();
    ds.adddir(ota_metadata_dir, true);
    // capture any ipsec policies in play. no keys are exposed here.
    runcommand("ip xfrm policy", {"ip", "xfrm", "policy"}, commandoptions::withtimeout(10).build());
    // dump ipsec stats. no keys are exposed here.
    dumpfile("xfrm stats", xfrm_stat_proc_file);
    // run ss as root so we can see socket marks.
    runcommand("detailed socket state", {"ss", "-eionptu"}, commandoptions::withtimeout(10).build());
    // run iotop as root to show top 100 io threads
    runcommand("iotop", {"iotop", "-n", "1", "-m", "100"});
    // gather shared memory buffer info if the product implements it
    runcommand("dmabuf dump", {"dmabuf_dump"});
    runcommand("dmabuf per-buffer/per-exporter/per-device stats", {"dmabuf_dump", "-b"});
    dumpfile("psi cpu", "/proc/pressure/cpu");
    dumpfile("psi memory", "/proc/pressure/memory");
    dumpfile("psi io", "/proc/pressure/io");
    if (dump_pool_) {
        return_if_user_denied_consent();
        dump_pool_->waitfortask(dump_traces_task);
        // current running thread in the pool is the root user also. shutdown
        // the pool and restart later to ensure all threads in the pool could
        // drop the root user.
        dump_pool_->shutdown();
    }
    if (!droprootuser()) {
        return dumpstate::runstatus::error;
    }
    return_if_user_denied_consent();
    dumpstate::runstatus status = dumpstate();
    // capture logcat since the last time we did it.
    dosystemlogcat(logcat_ts);
    return status;
}

/*
 * finalizes writing to the file by zipping the tmp file to the final location,
 * printing zipped file status, etc.
 */static void finalizefile() {    bool do_text_file = !ds.finishzipfile();
    if (do_text_file) {
        myloge("failed to finish zip file; sending text bugreport instead\n");
    }
    std::string final_path = ds.path_;
    if (ds.options_->outputtocustomfile()) {
        final_path = ds.getpath(ds.options_->out_dir, ".zip");
        android::os::copyfiletofile(ds.path_, final_path);
    }
    if (ds.options_->stream_to_socket) {
        android::os::copyfiletofd(ds.path_, ds.control_socket_fd_);
    } else if (ds.options_->progress_updates_to_socket) {
        if (do_text_file) {
            dprintf(ds.control_socket_fd_,
                    "fail:could not create zip file, check %s ""for more details\n",
                    ds.log_path_.c_str());
        } else {
            dprintf(ds.control_socket_fd_, "ok:%s\n", final_path.c_str());
        }
    }
}

// packages/modules/adb/client/bugreport.cpp
// custom callback used to handle the output of zipped bugreports.
class bugreportstandardstreamscallback : public standardstreamscallbackinterface {
  public:
    bugreportstandardstreamscallback(const std::string& dest_dir, const std::string& dest_file,
                                     bool show_progress, bugreport* br)
        : br_(br),
          src_file_(),
          dest_dir_(dest_dir),
          dest_file_(dest_file),
          line_message_(),
          invalid_lines_(),
          show_progress_(show_progress),
          status_(0),
          line_(),
          last_progress_percentage_(0) {
        setlinemessage("generating");
    }
    int done(int unused_) {
        // pull the generated bug report.
        if (status_ == 0) {
                        // 将bugreport-*.zip文件 pull到本地(host)
            status_ =
                br_->dosyncpull(srcs, destination.c_str(), false, line_message_.c_str()) ? 0 : 1;
            if (status_ == 0) {
                printf("bug report copied to %s\n", destination.c_str());
            } else {
                fprintf(stderr,
                        "bug report finished but could not be copied to '%s'.\n"
                        "try to run 'adb pull %s <directory>'\n"
                        "to copy it to a directory that can be written.\n",
                        destination.c_str(), src_file_.c_str());
            }
        }
        return status_;
    }
